Single Mode MTP Patch Cable with Polarity B for QSFP28 Transceivers

Brand Name:	NEW LIGHT
Model Number:	MPO / MTP - MPO / MTP
MOQ:	negotiation
Price:	0.1~100
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Name:

MPO MTP Cable

Material:

LSZH, OFNP Or OFNR

Mode Type:

Core Type:

12 Core

Delivery Time:

2-7 Working Days After Received Deposit

Production Ability:

500 Pcs / Day

Payment Term:

T/T , 30% Deposit In Advance

Connector:

MPO,MTP

Color:

Aqua,orange,yellow,Yellow/ Red/ Aqua

Supply Ability:

500 pcs per day

Highlight:

mpo fiber cable

mpo to mpo cable

Product Description

MTP Female to MTP Female Single Mode Cable Polarity B for QSFP28 Transceivers

MTP to MTP patch cables are designed for two primary applications: direct connection between two QSFP+ or QSFP28 transceivers, or connecting MTP trunk cables to QSFP+ or QSFP28 transceivers. These cables feature polarity B configuration with female connectors on both ends, enabling seamless SR4 transmission between QSFP transceivers.

Utilizing low loss MT ELITE ferrules and Corning Clearcurve glass, these MTP patch cables guarantee optimal performance and compatibility. As part of our M400 Series, they provide a complete network solution supporting both 40GBASE-SR4 and 100GBASE-SR4 applications.

MPO MTP Cable Applications

Multimode Fiber Applications (OM3/OM4 50/125)

Direct connection between two QSFP+ transceivers for 40GBase-SR4
Direct connection between two QSFP28 transceivers for 100GBase-SR4
Connection to MPO trunk cables

Singlemode Fiber Applications (OS1/OS2 9/125)

Direct connection between two QSFP+ PLR4 (LR4 PSM) transceivers for 40G Ethernet
Direct connection between two QSFP28 PLR4 (LR4 PSM) transceivers for 100G Ethernet
Connection to MPO trunk cables

Both multimode and singlemode patch cords typically feature polarity B configuration with female connectors.

MPO MTP Cable Features

US Conec MTP connector, Senko MPO Plus premium connector
OS2, OM3, OM4 fiber grades (OM1 and OM2 available)
0.35dB Elite low loss MTP/MPO connector as well as standard versions of 0.6/0.75dB
Factory terminated and tested
Easy migration from 10GbE to 40GbE or 100GbE
Pulling eyes available as optional protection during installation

Technical Parameters

Item	Technical Parameters
Connector	MPO/MTP (F or M) \| MPO/MTP (F or M)
Operation Temperature	-40°C ~ +80°C
Storage Temperature	-40°C ~ +85°C
Insertion Loss	SM: ≤ 0.75dB (standard), ≤0.35dB (typical); MM: ≤ 0.50dB (standard), ≤0.35dB (typical)
Return Loss	SM: ≥60dB; MM: ≥35dB
MPO End Type	Male: with guide pin; Female: without guide pin
Fiber Count	8, 12 & 24 fiber
Connector Type (Other End)	MPO-female, MPO-male, FC, SC, ST, MU, LC, E2000
Fiber Mode	Single-mode (G652, G655, G657), multi-mode (50, 62.5, OM2, OM3, OM4)
Fiber Cable Type	250um ribbon fiber, ribbon cable, bundle fiber optic cable

The three polarity methods Type A, Type B and Type C ensure proper bi-directional allocation for optimal performance.

Packaging

Products are packaged in OPP bags with carton boxes for external protection, ensuring safe delivery and protection from damage during transportation.

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer located in Shenzhen, China.

What's your MOQ?

MOQ can be 1 piece, but we recommend larger quantities for better pricing.

What's the price?

Pricing depends on quantity. We offer competitive pricing for bulk orders.

Can you quote FOB price?

We primarily ship via air couriers. EXW or CFR pricing is recommended for most orders.

How is your quality?

We follow IEC and European standards with imported production equipment. All products are 100% tested before delivery.

What's your lead time?

2-3 working days for 5000 pieces. Regular products are available from stock.

What's your warranty?

2-year warranty for patch cords, covering non-artificial damage.

Can you do OEM/ODM?

Yes, we accept OEM/ODM orders and can sign confidentiality agreements.

Can I have a sample?

Free samples available for some products with freight prepaid by customer.

Contact Information:
WhatsApp: +8613534063703
Payment Terms: T/T, Western Union, Paypal, MoneyGram
