Bare Fiber 250μm Stainless Steel Tube 1x2 PLC Splitter for Fiber Optic Signal Distribution

Brand Name:	New Light
Model Number:	Mini Type
MOQ:	10
Price:	1~30
Packaging Details:	export packing
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Product Name:

1 In 2 Out Mini Type PLC Splitter

Connector Type:

SC / E2000

Mode Type:

Single Mode

OEM / ODM:

Acceptable

Tube Materials:

Stainless Steel

Certificate:

CE , ISO , RoHS

Cable Length:

Cable Diameter:

0.9mm , 0.6mm, 0.25mm

Supply Ability:

1000000

Highlight:

fiber optic plc splitter

single mode fiber splitter

Product Description

Bare Fiber 250μm Steel Tube 1x2 PLC Fiber Splitter with Connector

Planar lightwave circuit (PLC) splitter is an optical power management device fabricated using silica optical waveguide technology to distribute optical signals from Central Office (CO) to multiple premise locations. This bare fiber splitter is designed for PON networks and can be installed in pigtail cassettes, test instruments, and WDM systems, minimizing space occupation.

PLC splitters utilize semiconductor technology and consist of one optical PLC chip coupled with optical arrays at both ends. The device uses silica glass as the material for lightwave circuits and features substrate, waveguide, and lid layers. Available in various configurations including bare, blockless, ABS, LGX box, mini plug-in, tray type, and 1U rack mount models.

Applications

FTTX Systems
PON Networks
CATV Links
Optical Signal Distribution

Features

Low Insertion Loss
Low Polarization Dependent Loss (PDL)
Compact Design
Excellent Channel-to-Channel Uniformity
Wide Operating Wavelength: 1260nm to 1650nm
Wide Operating Temperature: -40°C to 85°C
High Reliability and Stability

Compliance Standards

Telcordia GR-1209-CORE, Telcordia GR-1221-CORE, RoHS

Technical Specifications

Parameters	1*2	1*4	1*8	1*16	1*32	1*64
Operating Wavelength (nm)	1260~1650
Fiber Type	SMF-28e or customer specified
Insertion Loss (dB)(S/P Grade)	4.0/3.8	7.3/7.0	10.5/10.2	13.7/13.5	16.9/16.5	21.0/20.5
Loss Uniformity (dB)	0.4	0.6	0.8	1.2	1.5	2.5
Return Loss (dB) (S/P Grade)	50/55	50/55	50/55	50/55	50/55	50/55
Polarization Dependent Loss(dB)	0.2	0.2	0.3	0.3	0.3	0.4
Directivity (dB)	55	55	55	55	55	55
Wavelength Dependent Loss(dB)	0.3	0.3	0.3	0.5	0.5	0.5
Temperature Stability(-40~85 °C)(dB)	0.5	0.5	0.5	0.5	0.5	0.5
Operating Temperature (°C)	-40~85
Storage Temperature (°C)	-40~85
Module Dimension (mm) (LWH)	1008010	1008010	1008010	1208018	14011518	14011518

CAD Drawing & Dimensions

Tube Size: 50x4x4 mm

The PLC optical splitter MINI module is available in various split modes and package types, with customization options available according to customer requirements.

Packaging

Products are packaged in OPP bags with outer carton boxes to ensure protection during delivery and transportation.

Frequently Asked Questions

Q: Are you a manufacturer?

A: Yes, we are a manufacturer located in Shenzhen, China.

Q: What's your MOQ?

A: MOQ can be 1 piece, but we recommend larger quantities for better pricing as single-unit orders incur higher costs.

Q: What's the price?

A: Pricing is quantity-dependent. We provide competitive quotes based on your order volume.

Q: Can you quote FOB price?

A: We primarily ship via air couriers (DHL, TNT, UPS, FedEx). For large shipments, we can provide sea freight options. EXW or CFR pricing is typically preferred.

Q: How is your quality?

A: We manufacture according to IEC and European standards in near dust-free environments using imported production and quality control equipment. All products undergo 100% testing before delivery.

Q: What's your lead time?

A: We operate three factories in China. For fiber optic patch cords, lead time is 2-3 working days for 5,000 pieces. Regular products are typically in stock, and we accommodate urgent orders.

Q: What's your warranty?

A: Patch cords carry a 2-year warranty against non-artificial damage. For artificial damage, we provide free repairs with customer covering freight costs.

Q: What's your packing?

A: We use international export packaging and offer custom logo printing services.

Q: Can you do OEM/ODM?

A: Yes, we support OEM/ODM services and can sign confidentiality agreements.

Q: Can I have a sample?

A: Free samples available for adaptors, attenuators, patch cords, and pigtails (customer pays freight). Higher-value products require sample charges refundable with subsequent orders.

Q: How can I order?

A: Process: 1) Submit inquiry with specifications and quantity; 2) Receive quotation; 3) Accept and receive proforma invoice; 4) Production begins after payment; 5) Shipping confirmation with tracking; 6) Ongoing support for long-term cooperation.

Q: What are your payment terms?

A: T/T, Western Union, PayPal, MoneyGram. For large orders: 50% deposit, 50% balance before delivery.
