SC/APC Connector 1x32 Split Ratio PLC Fiber Splitter with ABS Module for FTTX Systems

Brand Name:	New Light
Model Number:	Mini Type
MOQ:	10
Price:	1~30
Packaging Details:	export packing
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Product Name:

1 In 2 Out Mini Type PLC Splitter

Connector Type:

SC / E2000

Mode Type:

Single Mode

OEM / ODM:

Acceptable

Tube Materials:

Stainless Steel

Certificate:

CE , ISO , RoHS

Cable Length:

Cable Diameter:

0.9mm , 0.6mm, 0.25mm

Supply Ability:

1000000

Highlight:

fiber optic plc splitter

single mode fiber splitter

Product Description

SC/APC Singlemode 1x32 PLC Fiber Splitter

This 2.0mm splice/pigtailed ABS module PLC fiber splitter utilizes planar lightwave circuit technology to efficiently distribute optical signals across multiple outputs. Available in various split configurations including 1xN and 2xN types to accommodate different subscriber requirements and cable lengths.

Technology Overview

PLC (Planar Lightwave Circuit) splitters employ micro-optical chips mounted on carriers with ribbon fibers. Constructed from silica glass with various polished finishes, these devices feature substrate, waveguide, and lid layers. Available in multiple packaging options including bare, blockless, ABS, LGX box, mini plug-in, tray type, and 1U rack mount configurations.

Applications

FTTX Systems
PON Networks
CATV Links
Optical Signal Distribution

Key Features

Low Insertion Loss
Low Polarization Dependent Loss (PDL)
Compact Design
Excellent Channel-to-Channel Uniformity
Wide Operating Wavelength: 1260nm to 1650nm
Broad Temperature Range: -40°C to 85°C
High Reliability and Stability

Compliance Standards

Telcordia GR-1209-CORE, Telcordia GR-1221-CORE, RoHS

Technical Specifications

Parameters	1*2	1*4	1*8	1*16	1*32	1*64
Operating Wavelength (nm)	1260~1650
Fiber Type	SMF-28e or customer specified
Insertion Loss (dB)(S/P Grade)	4.0/3.8	7.3/7.0	10.5/10.2	13.7/13.5	16.9/16.5	21.0/20.5
Loss Uniformity (dB)	0.4	0.6	0.8	1.2	1.5	2.5
Return Loss (dB) (S/P Grade)	50/55	50/55	50/55	50/55	50/55	50/55
Polarization Dependent Loss(dB)	0.2	0.2	0.3	0.3	0.3	0.4
Directivity (dB)	55	55	55	55	55	55
Wavelength Dependent Loss(dB)	0.3	0.3	0.3	0.5	0.5	0.5
Temperature Stability(-40~85 °C)(dB)	0.5	0.5	0.5	0.5	0.5	0.5
Operating Temperature (°C)	-40~85
Storage Temperature (°C)	-40~85
Module Dimension (mm) (LWH)	1008010	1008010	1008010	1208018	14011518	14011518

CAD Drawing & Dimensions

Tube size: 50x4x4 mm

Our PLC optical splitter MINI modules are available in various split modes and package types, with customization options to meet specific customer requirements.

Packaging

Expertly designed export packaging ensures products arrive in perfect condition, with optional custom logo printing available.

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer located in Shenzhen, China.

What's your minimum order quantity (MOQ)?

MOQ can be 1 piece, though larger quantities receive more competitive pricing.

What's the price?

Pricing varies by quantity. Contact us with your requirements for our best pricing.

Can you quote FOB price?

We typically ship via air courier. EXW or CFR pricing is preferred for most orders.

How is your quality?

We adhere to IEC standards with imported production equipment and 100% product testing before delivery.

What's your lead time?

Standard products are often in stock. Custom orders typically require 2-3 working days for production.

What's your warranty?

2-year warranty for non-artificial damage. Repair services available for other issues.

What's your packing?

International export packaging with custom logo printing available.

Can you do OEM/ODM?

Yes, we support OEM/ODM and can sign confidentiality agreements.

Can I have a sample?

Free samples available for some products with freight prepaid. Sample charges apply for high-value items.

How can I order?

What are your payment terms?

T/T, Western Union, Paypal, MoneyGram. Large orders may require 50% deposit with balance before delivery.
