IP68 Waterproof Customizable Length FTTA Optical Fiber Patch Cord Fiber Optic Patch Cable

Brand Name:	NewLight
Model Number:	NL001
MOQ:	1~100000
Price:	0.1~100
Packaging Details:	1 pcs per pack
Payment Terms:	T/T,Western Union,MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Connector:

LC-LC

Application:

FTTA FTTH BBU RRU RRH LTE & Base Station,For ODF Internal Link,For Room Equipment Internal Link,FTTH/Test Equipments/TV/LAN/Telecommunication Equipments

Length:

Any Length Is Customizable

Connector Type:

SC/FC/LC/ST/MU/DIN/D4/MTRJ/MPO

Type:

Single Mode/Multi-mode

Material:

PVC/LSZH

Color:

Yellow,Orange Or Others,aqua Or Cusomized

Wavelength:

850 Nm,1310nm,1310nm Or 1550nm

Fiber Type:

G652D,G655,anything,SM Or MM

Connector:

LC-LC

Application:

FTTA FTTH BBU RRU RRH LTE & Base Station,For ODF Internal Link,For Room Equipment Internal Link,FTTH/Test Equipments/TV/LAN/Telecommunication Equipments

Length:

Any Length Is Customizable

Connector Type:

SC/FC/LC/ST/MU/DIN/D4/MTRJ/MPO

Type:

Single Mode/Multi-mode

Material:

PVC/LSZH

Color:

Yellow,Orange Or Others,aqua Or Cusomized

Wavelength:

850 Nm,1310nm,1310nm Or 1550nm

Fiber Type:

G652D,G655,anything,SM Or MM

Supply Ability:

1000000

Highlight:

sc sc fiber patch cord

single mode fiber optic cable

Product Description

Customized FTTA Optical Fiber Patch Cord

Professional waterproof FTTA fiber optic patch cords with IP68 fiber H connectors designed for outdoor applications.

Product Overview

Outdoor waterproof Optical Fiber OptiTap SC/APC Drop Patch Cords Cables Jumpers with copper wire, featuring PE outer jacket materials. These fiber optic outdoor jumper assemblies are available in various sizes including 3.0mm, 5.0mm, and 4.5*8.0mm OptiTap SC/APC configurations.

Key Features & Benefits

Smaller profile with reduced bend-radius
Designed for rapid connection to external flush-mounted bulkhead adapters
Robust design maintains connector integrity during installation
Integral pulling eye/connector cap supports 100 lb maximum pulling tension
Easy-to-connect screw closure system
Double cable cover 4.6mm XTREMDROP design
High effectiveness with low insertion loss performance
IP67 protection against water and dust in rigorous environments
Wide operating temperature range: -40°C to 70°C
Compatible with DualDrop hoses and other drop-in cables

Technical Specifications

Temperature Range: Operation -40°C to 70°C (-40°F to 158°F)

Optical Specifications: Insertion loss typical ≤ 0.3 dB, Reflectance typical > -60 dB

Parameter	Single-mode	Multi-mode
Insertion Loss	≦0.3dB
Return Loss	≧50 dB(PC)	≧60 dB(APC)
Repeatability	≦0.1dB
Durability	0.2dB Max, 1000 matings
Operating Temperature	-40℃ ~ 80℃
Storage Temperature	-40℃ ~ 81℃

Additional Features

Cost-effective solution for in-house termination
IP67 water immersion and dust protection for harsh environments
Chemical resistance
Simple assembly requiring no special tools
Push-pull insertion with bayonet-style mechanical latch
Durable mechanical mating, minimum of 500 matings
Wide operational temperature range: -40 to +85°C
SC/APC IL<0.3 typically
100% optically tested for quality performance

Ordering Options

Both singlemode and multimode fiber optic patch cords feature zirconia ceramic ferrules with pre-polished PC, UPC, and APC profiles with convex spherical ends for faster polishing, low back reflection, and minimal optical loss.

Available Configurations

Connector type: FC, SC, ST, LC, MT-RJ, MU, etc.
Ferrule endface: PC, UPC, APC, etc.
Fiber type: Single mode, polarization-maintaining, multimode 50/125, multimode 62.5/125, etc.
Cable diameter: 0.9mm, 2.0mm, 3.0mm, etc.
Number of fibers: Single-core, dual-core, and multi-core connectors

Quality Standards

Good durability and exchangeability
High temperature stability
Low insertion loss and back reflection loss
Superior quality standard PC/UPC/APC polishing
Compliant with Telcordia GR-326-CORE, TIA/EIA and IEC standards

Frequently Asked Questions

Are you a trading company or manufacturer?

We are the factory.

How long is your delivery time?

Generally 7-15 days if goods are in stock, or 15-30 days if not in stock, depending on quantity.

Do you provide samples? Is it free or extra?

Yes, we offer samples free of charge but the customer pays for freight.

How about your after-sales service?

We offer 24-hour phone service and 9-hour email support.

What are your payment terms?

Payment ≤ $10,000 USD: 100% in advance. Payment ≥ $10,000 USD: 30% T/T in advance, balance before shipment.

Contact Information

For any additional questions, please contact us:

Email: sales03@newlightfiber.com

Phone: 0086 13534063703
