Aerial Uni Loose Tube 8 Optic Fiber Cable Self Supported Figure GYXTC8Y

Aerial Uni Loose Tube 8 Optic Fiber Cable Self Supported Figure GYXTC8Y
Aerial Uni Loose Tube 8 Optic Fiber Cable Self Supported Figure GYXTC8Y
Aerial Uni Loose Tube 8 Optic Fiber Cable Self Supported Figure GYXTC8Y Aerial Uni Loose Tube 8 Optic Fiber Cable Self Supported Figure GYXTC8Y Aerial Uni Loose Tube 8 Optic Fiber Cable Self Supported Figure GYXTC8Y Aerial Uni Loose Tube 8 Optic Fiber Cable Self Supported Figure GYXTC8Y

Large Image :  Aerial Uni Loose Tube 8 Optic Fiber Cable Self Supported Figure GYXTC8Y

Product Details:
Place of Origin: China
Brand Name: NL
Certification: ISO9001; ROSH
Model Number: NL
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiable
Packaging Details: Wooden wheel
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T
Supply Ability: 10000 m per day

Aerial Uni Loose Tube 8 Optic Fiber Cable Self Supported Figure GYXTC8Y

Description
Fiber Type: Singlemode G652D ,G657A Outer Jacket Material: LSZH
Strength Member Material: KFRP / FRP / Steel Wire Packaging: Wooden Wheel
Test Repor: Out Package Of The Cable Fiber Struction: Figure8
Usage: Aerial Certification: ISO9001,ROHS,CE,CE And ROHS,ISO9001/CE/ROHS
Type: Single-Mode Or Multi-Mode Jacket Material: LSZH,PVC,PE,TPU,PVC/LSZH
High Light:

duplex fiber optic patch cable

,

fiber optic drop cable

Aerial Uni Loose Tube Self Supported Figure 8 Optic Fiber Cable Price GYXTC8Y

Features and Applications
•Small cable diameter, cross section shows figure 8
•Self-supporting stranded wires, easily to install
•Excellent mechanical and environmental performance
•High strength loose tube that is hydrolysis resistant
•Medium density polyethylene jacket, low friction installation
•Outdoor aerial application
•Used for long-haul communication
•Subscriber network systems
•Junction communication systems
•CATV & Computer networks system

Description

The cable core is composed of loose tubes each with up to 2-24 fibers. The metal strength member is made up of stranded wires as the supporting part are completed with a polyethylene(PE) sheath to be figure 8 structure. High strength loose tube that is hydrolysis resistant. GYXTC8Y is an ideal self-supporting outdoor cable,used for aerial installation.

Standards
Cable complies with Standard YD/T 901-2001as well as IEC 60794-1.


  G.652 G.655 50/125μm 62.5/125μm
Attenuation @850nm     ≤3.0 dB/km ≤3.0 dB/km
(+20) @1300nm     ≤1.0 dB/km ≤1.0 dB/km
  @1310nm ≤0.36 dB/km ≤0.40 dB/km
  @1550nm ≤0.22 dB/km ≤0.23dB/km
Bandwidth (Class A) @850nm     ≥500 MHz·km ≥200 MHz·km
@1300nm     ≥1000 MHz·km ≥600 MHz·km
Numerical Aperture     0.200±0.015NA 0.275±0.015NA
Cable Cut-off Wavelength λcc ≤1260nm ≤1480nm





Packing

Aerial Uni Loose Tube 8 Optic Fiber Cable Self Supported Figure GYXTC8Y 0

Aerial Uni Loose Tube 8 Optic Fiber Cable Self Supported Figure GYXTC8Y 1



Item Index
Length and packaging 2000m/3000 plywood reel
Packaging details wooden wheel




Application

Ideal Solution for Tight-Buffered Distribution Waterproof Indoor/Outdoor Cable
Distribution waterproof indoor/outdoor cable is easy to install and handle. With high mechanical strength, rodent and waterproof protection, the ideal application of the cable is for LAN backbones, direct burial, ducts, trunking, and under floor or ceiling spaces.

Aerial Uni Loose Tube 8 Optic Fiber Cable Self Supported Figure GYXTC8Y 2




Packaging & Shipping
NEW LIGHT offers standardized packaging of cable, and we can ship it as soon as possible for adequate inventory. We pack the cable with roll, then put it into carton. The package provide good protection for cable. Usually we only attach test report on the out package of the cable, but we could also mark as your requirements.



FAQ
Q:Are you trading company or manufacturer ?
A:We are factory.
Q:How long is your delivery time?
A:Generally it is 7-15 days if the goods are in stock . Or it is 15-30 days if the goods are not in stock, it is according to quantity.
Q:Do you provide samples ? Is it free or extra ?
A:Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q:How about your after-sales service?
A:We offer you 24 hours service phone, 9 hours with mail.
Q:What is your terms of payment ?
A:Payment<=10000USD, 100% in advance . Payment>=10000USD, 30% T/T in advance , balance before shippment.
