19'' / 23'' Rack Mounted Fiber Optic Patch Panel 12 / 24 Core Drawer Slidable

19'' / 23'' Rack Mounted Fiber Optic Patch Panel 12 / 24 Core Drawer Slidable

    • 19'' / 23'' Rack Mounted Fiber Optic Patch Panel 12 / 24 Core Drawer Slidable
    • 19'' / 23'' Rack Mounted Fiber Optic Patch Panel 12 / 24 Core Drawer Slidable
  • 19'' / 23'' Rack Mounted Fiber Optic Patch Panel 12 / 24 Core Drawer Slidable

    Product Details:

    Place of Origin: China
    Brand Name: Newlight
    Certification: ISO9001,ROSH
    Model Number: NL013

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: can be negotiated
    Packaging Details: opp bag + carton box
    Delivery Time: 2-10 working days
    Payment Terms: T/T, Western Union, MoneyGram, paypal
    Supply Ability: 2000 Nos per month
    Contact Now
    Detailed Product Description
    Manufacturers Name: NewLight Country Of Origin: China
    Material: Cold-roll Steel Splicing Unit: 12fiber
    Adapters: FC, SC, ST, LC Dimension: 30*30*8.5cm
    Fiber Quantity: 10 /12/24 Type: Indoor Wall-mount
    Aplication: Management Fiber
    High Light:

    fiber optic accessories

    ,

    fiber optic termination panel

    19''  / 23'' 12 / 24 core drawer slidable rack mounted fiber optic patch panel





    Description



    Slidable Rack-mount Fiber Optic Distribution Frame has aluminum sliding fittings with self-locking functions prevent the drawer from falling when moved; 19-inch rack mount for ST, SC, LC, MTRJ, FC,etc. adapters. And Fiber Quantity can be 12 core, 24 core, 48 core, 96 core etc.The drawer is the holding board for splicing, easy to withdraw the fibers when testing and distributing.

    Product Features

    Cold-roll steel, electrostatic painting
    ABS plastic tray inside, 12~24 cores per tray
    Different adapter plate available: FC, SC, LC, ST…
    Cable entry ports suitable for single fiber, bundle & ribbon fiber cables
    Reasonable design ensures the cables are in good order
    19-inch sliding-out type, easy to operate
    4 fiber cable entry ports at rear side
    Simplex and duplex FC, LC, SC, ST adapters optional
    12, 24, 48, 96 cores available
    White or black color
    Standard size, light weight and reasonable structure

    1) Standard size, light weight and reasonable structure
    2) Can be used in 19'', 23'' standard distribution frame
    3) Suitable for ribbon and single fiber
    4) Various panel plate to fit different adapter interface
    5) Front mark on the plate is easy for identification and operation

    Features:

    1, Interface optional: SC/FC/LC/ST etc.
    2, Cores optional: 12/24/36/48/72/96/144 etc.
    3, Standard size, light weight and reasonable structure
    4, Slide out drawer for easy cable management
    5, Suitable for ribbon and single fiber
    6, Compact design for space saving
    7, Various panel plate to fit different adapter interface
    8, Front mark on the plate is easy for identification and operation
    9, Easy for management and operation



    Application

    Local Area Network
    CATV Network
    FTTx System
    Wide Area Network
    Test Instruments

    Specification

    Technical Parameters

    Material Steel and ABS plastic

    Finished product black appearance


    Working temperature -40℃ ~ + 60℃
    Design standard TIA/EIA568.C, ISO/IEC 11801, En50173, IEC60304, IEC61754, EN-297-1
    Curvature radius ≥40mm
    Extra loss in the splice tray none
    Lateral pressure-resistance 500N
    Resistance 750N





    Specificate

    Mode fiber quantity dimension weight
    ODF-12B 12/24 285*317*45.5cm 4.5



    19'' / 23'' Rack Mounted Fiber Optic Patch Panel 12 / 24 Core Drawer Slidable

    Packing & Delivery


    Trade Info:
    Trade terms: FOB,CIF,CFR,etc
    Price Terms: T/T,Western Union,Paypal
    Payment Terms: T/T in advance
    MOQ:1 pcs
    Port: Shenzhen
    Lead time: Within 5 working days after receiving payment.
    Shipment: Express, Air
    Sample availability: Yes( not free)
    Package information: carton/wooden package







    FQA



    1. Q : Are you manufacturer ?

    A: yes, we are manufacturer in Shenzhen,China



    2. Q : What's your MOQ ?

    A: MOQ can be 1 pcs , but we are not suggest to order 1 pcs , because the cost will be higher , so that the price will be higher than your budget .



    3. Q : What's the price ?

    A : The price is according to your quantity . After you let us know your quantity , we will offer our best price for you . Big Quantity will get very competitive price .



    4. Q: Can you quote FOB price ?

    A : yes we can , But due to the size and weight is not big , most are delivery by air ,DHL , TNT , UPC , FEDEX ,etc . So it it difficult to do FOB price . The best way is let us know your detailed specifications and quantity , we will offer the freight with products price for your reference .



    We have very competitive price logist . If your quantity is big and there are dozens of carton boxes , we can figure out freight by sea for your reference .



    EXW price or CFR price will be better . You can contact us for more solution if you need .



    5. Q: How is your quality ?

    A: Our production is according to IEC , Europe standard production , almost closed to dust-free workshop . Imported production equipment and quality control equipment . Especially MTP Daisi equipments .



    All the products are 100% test before delivery .



    6. Q : Whats your lead time ?

    A : We have three factories in China . One factory for fiber optic cable production , two factories for patch cord , PLC , ODF , adaptor ,attenuators ,etc .

    For fiber optic patch cord , the lead time can be 2 -3 owrking days for 5000 pcs . regular products we are have it in stock . We can deal with urgent order for you . More informations , you can feel free to contact us .



    7. Q : Whats your warranty ?

    A : for patch cord , we have 2 years warranty since delivery , but only responsible for non-artificial damage . For artificial damage , we can repare it for you for free ,but freight will be paid by your side .



    8. Q : Whats your packing ?

    A : We are using international export package . attached some packing of different products for your reference . We also can print your logo on the packing



    9. Q: Can you do OEM/ODM ?

    A: yes , we can . We are manufacturer , all products are accept OEM /ODM . we can sign the Confidentiality agreement .



    10. Q: Can I have a sample ?

    A: It depends on which products , for adaptor , attenuator ,patch cord , pigtail , we can provide a sammple for you for free . But freight repaid by your side .

    For big value products , we can't offer it for free , sample charge and freight repaid first , after you placed order , the sample charge will be returned.



    11. Q: How can I order ?

    A: 1. send mail to us or send inquiry . let us know the products name , detailed specifications , quantity . Provide your receive address if you need us to figure out freight for you .

    2. After we know your requirements , will offer our best price for you ,with lead time . The price is according to your quantity .

    3. When you accept the quotation , we will make Profoma Invoice with our bank account .

    4. We will arrange the production for you after we received payment .

    5. Before we delivery will confirm the receive information with you again .and will send the tracking number to you after delivery .

    6. We will try our best to meet your requirements for long-term cooperation .



    12. Q: What your payment term ?

    A: T/T , Western Union , Paypal ,MoneyGram at once .For big amount , can 50% deposit in advance , 50% balance paid before delivery .
