1U Wall Mount Fiber Optic Patch Panel with OM3/OM4 Multimode Support and 12 Fiber Splicing Unit

Brand Name:	Newlight
Model Number:	NL013
MOQ:	1~10000
Price:	10~100
Packaging Details:	opp bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001,ROSH

Manufacturers Name:

NewLight

Country Of Origin:

China

Material:

Cold-roll Steel

Splicing Unit:

12fiber

Adapters:

FC, SC, ST, LC

Dimension:

30*30*8.5cm

Fiber Quantity:

10 /12/24

Type:

Indoor Wall-mount

Aplication:

Management Fiber

Supply Ability:

2000 Nos per month

Highlight:

fiber optic accessories

fiber optic termination panel

Product Description

1U 96 Fiber OM3/OM4 Multimode Fiber Optic Patch Panel - Wall Mount

This standard 1U rack-mounted fiber optic patch panel supports LC/SC/MTP adapters and serves as the intermediate connection between backbone and patch cables. Available in single mode and multimode fiber types with various adapter options and port counts.

Product Overview

A fiber optic patch panel (also known as patch bay, patch field, or jack field) is a mounted hardware assembly containing multiple ports to manage incoming and outgoing fiber or copper cables. In data center infrastructure, patch panels are typically placed in wiring closets to interconnect racks, with patch cords connecting servers or network switches to the front panel ports.

Key Features

Constructed from cold-roll steel with electrostatic painting
ABS plastic tray interior, 12-24 cores per tray
Multiple adapter plate options: FC, SC, LC, ST
Cable entry ports suitable for single fiber, bundle & ribbon fiber cables
Optimized design for organized cable management
19-inch sliding-out type for easy operation
4 fiber cable entry ports at rear side
Simplex and duplex FC, LC, SC, ST adapters available
Multiple core options: 12, 24, 48, 96 cores
Available in white or black color
Standard size with lightweight, rational structure
Compatible with 19", 23" standard distribution frames
Front marking for easy identification and operation

Technical Specifications

Parameter	Specification
Material	Steel and ABS plastic
Appearance	Black finish
Working Temperature	-40℃ to +60℃
Design Standards	TIA/EIA568.C, ISO/IEC 11801, En50173, IEC60304, IEC61754, EN-297-1
Curvature Radius	≥40mm
Extra Loss in Splice Tray	None
Lateral Pressure Resistance	500N
Resistance	750N

Model Specifications

Model	Fiber Quantity	Dimensions	Weight
ODF-12B	12/24	28531745.5cm	4.5kg

Product Images

Applications

Local Area Network (LAN)
CATV Network
FTTx System
Wide Area Network (WAN)
Test Instruments

Ordering & Shipping Information

Trade Terms: FOB, CIF, CFR, etc.
Payment Methods: T/T, Western Union, PayPal
Payment Terms: T/T in advance
Minimum Order Quantity: 1 piece
Port: Shenzhen
Lead Time: Within 5 working days after payment
Shipping Methods: Express, Air
Samples: Available (not free)
Packaging: Carton/wooden package

Frequently Asked Questions

Q: Are you a manufacturer?

A: Yes, we are a manufacturer located in Shenzhen, China.

Q: What's your MOQ?

A: MOQ is 1 piece, though larger quantities receive more competitive pricing.

Q: What's the price?

A: Pricing varies by quantity. Contact us with your requirements for our best pricing.

Q: Can you quote FOB price?

A: Yes, though most shipments are via air freight. EXW or CFR pricing may be more suitable.

Q: How is your quality?

A: We follow IEC and European standards with imported production equipment and 100% testing before delivery.

Q: What's your lead time?

A: Regular products are in stock. Custom orders typically take 2-3 working days for 5000 pieces.

Q: What's your warranty?

A: 2-year warranty for patch cords (non-artificial damage only).

Q: What's your packaging?

A: International export packaging with optional custom logo printing.

Q: Can you do OEM/ODM?

A: Yes, we accept OEM/ODM orders and can sign confidentiality agreements.

Q: Can I have a sample?

A: Free samples available for adapters, attenuators, patch cords, and pigtails (freight paid by customer).

Q: How can I order?

A: Contact us with product specifications and quantity. We'll provide pricing and lead time, then issue a proforma invoice upon acceptance.

Q: What are your payment terms?

A: T/T, Western Union, PayPal. For large orders: 50% deposit, 50% balance before delivery.
