1U Rack Mount Fiber Optic Patch Panel with Slide-Out Tray and 12/24/48 Fiber Capacity for Easy Management

Brand Name:	Newlight
Model Number:	NL013
MOQ:	1~10000
Price:	10~100
Packaging Details:	opp bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001,ROSH

Manufacturers Name:

NewLight

Country Of Origin:

China

Material:

Cold-roll Steel

Splicing Unit:

12fiber

Adapters:

FC, SC, ST, LC

Dimension:

30*30*8.5cm

Fiber Quantity:

10 /12/24

Type:

Indoor Wall-mount

Aplication:

Management Fiber

Supply Ability:

2000 Nos per month

Highlight:

fiber optic accessories

fiber optic termination panel

Product Description

Single Mode or Multimode Fiber Optic Patch Panel Rack Mount

Product Overview

1U LC duplex fiber optic sliding rack mount patch panels preloaded with LC duplex adapters and simple splice management kit. Features an adjustable working tray that can be set to 10 degrees or lowered to 45 degrees for optimal maintenance access when installed in fiber optic rack cabinets.

Key Features

Available in 12, 24, 36, 48, and 72 port configurations
Cold-roll steel construction with electrostatic painting
ABS plastic tray interior, 12-24 cores per tray
Multiple adapter plate options: FC, SC, LC, ST
4 fiber cable entry ports at rear side
Slide-out drawer design for easy cable management
Suitable for ribbon and single fiber cables
Compact design for space optimization
Front marking for easy identification and operation
Available in white or black color options

Applications

Local Area Networks
CATV Networks
FTTx Systems
Wide Area Networks
Test Instruments

Technical Specifications

Parameter	Specification
Material	Steel and ABS plastic
Working Temperature	-40℃ to +60℃
Design Standards	TIA/EIA568.C, ISO/IEC 11801, En50173, IEC60304, IEC61754, EN-297-1
Curvature Radius	≥40mm
Lateral Pressure Resistance	500N
Resistance	750N

Product Dimensions

Model	Fiber Quantity	Dimensions	Weight
ODF-12B	12/24	28531745.5cm	4.5kg

Ordering & Shipping Information

Trade Terms

FOB, CIF, CFR, etc.

Payment Options

T/T, Western Union, PayPal

Order Details

Minimum Order Quantity: 1 piece
Port: Shenzhen
Lead Time: Within 5 working days after payment
Shipping Methods: Express, Air
Samples: Available (not free)
Packaging: Carton/wooden package

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer located in Shenzhen, China.

What's your MOQ?

MOQ is 1 piece, but we recommend larger quantities for better pricing.

What's the price?

Pricing varies by quantity. Contact us with your requirements for competitive pricing.

Can you quote FOB price?

Yes, but due to product size, air shipping is typically recommended. EXW or CFR pricing may be more suitable.

How is your quality?

We follow IEC and European standards with imported production equipment. All products are 100% tested before delivery.

What's your lead time?

We have three factories in China. For fiber optic patch cords, lead time is 2-3 working days for 5000 pieces. Regular products are in stock.

What's your warranty?

2-year warranty for patch cords for non-artificial damage. Repair services available for artificial damage with customer-paid freight.

Can you do OEM/ODM?

Yes, we accept OEM/ODM orders and can sign confidentiality agreements.

Can I have a sample?

Free samples available for adapters, attenuators, patch cords, and pigtails (customer pays freight). Sample charges apply for high-value products.
