Multimode LC Fiber Optic Connectors with 0.9mm 2.0mm and 3.0mm Options for High-Performance Networks

Brand Name: New Light
Model Number: LC
MOQ: 100
Price: 0.1~100
Packaging Details: standard export package
Payment Terms: T/T,Western Union,MoneyGram,paypal
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE / ISO / RoHS
Material:
Metal
Mode Type:
Single Mode / Multi Mode
Connector Type:
3.0mm
Insertion Loss:
<0.3dB
Certificate:
CE , ISO , RoHS
Return Loss:
PC≥40 UPC≥50 APC≥60 DB
Supply Ability:
10,000 pcs per month
Highlight:

2.0mm Fiber Optic Connectors

,

0.9mm Fiber Optic Connectors

,

2.0mm simplex fiber optic connector

Product Description
LC Fiber Optic Connectors
Simplex and duplex LC connectors available in 0.9mm, 2.0mm, and 3.0mm multimode fiber optic configurations. The LC connector features a 1.25mm ferrule size and is designed for high-performance networking applications with low insertion loss and reliable performance.
Product Overview
Originally developed by Lucent Technologies, LC connectors meet EIA/TIA-604-10 standards and are rated for 500 mating cycles with typical insertion loss of 0.25 dB. These connectors feature a compact design with split-sleeve construction and push-and-latch mechanism for secure rack mounting.
Standards Compliance
  • Telcordia GR-326-CORE for single-mode optical connectors
  • IEC 874-1 fiber optic connectors and cables
  • ANSI/TIA-568-C.3, ISO/IEC 11801 2nd Ed.
  • CENELEC EN 50173, UL94V-0
  • Cable flame resistant rate: OFNR or IEC60332-3 standard
Key Features
Performance
100% tested for insertion loss, specified length, and return loss
Design
Low insertion loss and back reflection with pull-proof design
Materials
High concentricity ceramic ferrules and corrosion-resistant bodies
Options
Available in PVC or LSZH jackets with multiple color options
Applications
Our fiber optic connectors are suitable for various industrial and commercial applications:
  • CATV and telecommunication networks
  • Local Area Networks (LANs) and Wide Area Networks (WANs)
  • Data processing networks and metro networks
  • Active device termination and test equipment
  • Industrial, medical, and military applications
  • Precise installations and distribution systems
APC Connector Technology
APC (Angled Physical Contact) connectors feature a 5° to 15° angle-polish on end faces to minimize back reflection. These connectors are identifiable by green strain relief boots or green connector bodies and provide return loss greater than -65 dB when mated.
Multimode LC Fiber Optic Connectors with 0.9mm 2.0mm and 3.0mm Options for High-Performance Networks 0
Note: APC connectors must only be mated with other APC connectors to maintain optimal performance.
Technical Specifications
Parameter Specification
Product Name OEM/ODM 3.0mm Fiber Optic ST Connector
Mode Type Single mode / Multi mode
Cable Diameter 0.9mm / 2.0mm / 3.0mm
Insertion Loss ≤ 0.3dB (low insertion loss can be ≤ 0.35dB)
Return Loss ≥60 dB
Wavelength 1310/1550 nm
Ferrule Material Ceramic
Operating Temperature -40°C to +85°C
Warranty 3 years after delivery
Delivery Time 2-15 working days (depending on quantity)
Available Connector Types
Multimode LC Fiber Optic Connectors with 0.9mm 2.0mm and 3.0mm Options for High-Performance Networks 1
Connector Type Mode Type Cable Type
LC / SC / FC / E2000 / MPO / MTRJ / SMA Single mode or Multimode 0.9mm / 2.0mm / 3.0mm
Ordering Information
When placing an order, please specify the following details:
  • Connector type: SC, FC, LC, ST, MPO, MTP, MU, MTRJ, E2000, SMA
  • Mode type: Single mode (UPC and APC) / Multi mode (PC)
  • Cable diameter: 0.9mm, 2.0mm, 3.0mm (custom diameters available)
  • Coating material: PVC or LSZH
  • Fiber count: Simplex, duplex, 4 core, 6 core, 8 core, 12 core, 24 core, 48 core, 96 core
  • Cable type: G652D, G657A1, G657A2, G655, OM1, OM2, OM3-150, OM3-300, OM4, OM5
  • Patch cord length: Custom lengths available
  • For MPO/MTP connectors: Specify method (A/B/C type), male/female, and fiber count
