Fiber Optic Pigtail

2m LC UPC Simplex OS2 Yellow Fiber Optic Pigtail with 0.9mm Diameter Low Insertion Loss and High Return Loss

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

2m LC UPC Simplex OS2 Yellow Fiber Optic Pigtail with 0.9mm Diameter Low Insertion Loss and High Return Loss

Brand Name:	New Light
Model Number:	SC/ PC
MOQ:	1
Price:	0.2~10
Packaging Details:	OPP bag + carton box
Payment Terms:	L/C,T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE , ISO , RoHS

Products Name:

SC / APC Optic Fiber Pigtail 12 Color 0.9 Mm 2 M Optic Fiber Jumping Cable

Connector Type:

SC( Can Be ST , FC , LC , MPO , MTRJ , MU )

Mode Type:

Multi Mode

Cable Color:

Purple (according To Your Request)

Cable Diameter:

0.9mm

Cable Length:

1 M (can Be Customized )

Insertion Loss:

≤ 0.3 DB

Return Loss:

≥ 40dB

Delivery Time:

2-7 Working Days

Payment Term:

30% Deposit In Advance , 70% Balance Paid Before Delivery

Supply Ability:

1000000

Highlight:

OS2 Yellow Fiber Optic Cable

7ft Yellow Fiber Optic Cable

OS2 fiber optic pigtail cables

Product Description

2m 7ft LC UPC Simplex OS2 Yellow Fiber Optic Cable

2m (7ft) LC UPC Simplex OS2 Single Mode PVC (OFNR) yellow fiber optic cable

Fiber optic cabling and hardware products including single mode and multimode fiber patch cables of 62.5/125, 50/125, and 9/125, and fiber distribution products used in high-tech networking.

Single-mode fiber provides higher transmission rates and up to 50 times more distance than multimode fiber, though at a higher cost. The small core and single light-wave virtually eliminate distortion from overlapping light pulses, delivering minimal signal attenuation and the highest transmission speeds available.

Technical Standards

LC: TIA/EIA, FOCIS10, GR-326 EIA/TIA-604-10, IEC61754-20 and JIS C5973

Key Features

Low insertion loss
High return loss
Good repeatability
Good interchange
Excellent environmental adaptability

Applications

Communication rooms
FTTH (Fiber to The Home)
LAN (Local Area Network)
FOS (fiber optic sensor)
Fiber Optic Communication System
Optical fiber connected and transmitting equipment
Defense combat readiness

Product Specifications

OM4 SC/PC Fiber Optic Pigtail

Product Name	OM4 SC / PC Fiber Optic Pigtail, 1 M Fiber Jumper Cables 12 Colors 0.9mm
Model Number	Pigtail SC OM4
Diameter	0.9/2.0/3.0
Connector	SC/LC/FC/ST/MPO
Cable length	1.2.3...Customized
Polishing	Yes, polished
Material	LSZH/PVC
Form of sale	OEM/ODM
Use	Connect the optical transmitter, receiver, and the terminal box
Custom Design	Welcome
Sample Lead Time	1-3 days
Certificate	CE, ROHS
Advantage	Low IL, High RL

Technical Parameters

Parameter	Unit	FC, SC, LC	ST, MU	MT-RJ, MPO	E2000
Insertion loss (typical)	dB	≤ 0.3	≤ 0.3	≤ 0.3	≤ 0.3
Return loss	dB	≥ 50	≥ 30	≥ 50	≥ 55
Operating wavelength	nm	1310, 1550	1300(OM1)850	1310, 1550	1310, 1550
Exchangeability	dB	≤ 0.2	≤ 0.2	≤ 0.2	≤ 0.2
Vibration	dB	≤ 0.2	≤ 0.2	≤ 0.2	≤ 0.2
Operating temperature		-40~75	-40~75	-40~75	-40~75
Storage temperature		-45~85	-45~85	-45~85	-45~85
Cable diameter	mm	φ 3.0, φ 2.0, φ 0.9	φ 3.0, φ 2.0, φ 0.9	φ 3.0, φ 2.0, φ 0.9	φ 3.0, φ 2.0

Applications

A Variety of Applications for Different Equipment

Widely used in CATV, FTTH/FTTX, telecommunication networks, premise installations, data processing networks, LAN/WAN network, and more.

WHATSAPP 008613534063703

Frequently Asked Questions

Are you the real manufacturer?
We are the real manufacturer with 15 years of experience.
What's the MOQ?
The MOQ of Fiber Optic cable is 1km.
What's delivery time?
The general delivery time is 5-7 days after order confirmed. It depends on the order quantity.
How to Store the Optical Fiber Cable Properly?
Store the drum indoor before using, the drum should place sideways not on the end.
Can you supply customized products and logo?
Yes. We supply OEM service. You can send us your drawing.
What's your payment terms?
We accept T/T, L/C, Western Union, D/P etc. 30% in advance and 70% before shipment.

Payment Terms and Delivery

Payment: T/T, L/C, Paypal, Western Union, Moneygram

Terms: 30% deposit in advance, 70% balance paid before delivery

Package: International standard package (OPP bag + Carton Box)

Delivery time: 2-7 working days (according to your quantity) after received payment

Warranty: 3 years (after delivery)

Shipping method: By air (DHL, TNT, UPS, Fedex), By sea (according to your requirements)
