Single Mode MPO Fiber Jumper 1300nm 12F Breakout Cable with Low Insertion Loss

Brand Name:	New Light
Model Number:	MPO -12*LC
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Product Name:

SS-OPMPO12-4*DLCM

Connector Type:

MPO- 8*LC

Core Type:

50/125um

Insertion Loss:

Insertion Loss ≤ 0.5dB

Cable Length:

Customized

Fiber Type:

Fiber Count:

8 FIBER

Jacket:

Cable Diameter:

3.5mm

Cable Color:

MPO Type:

Male Type

Supply Ability:

500 pcs per day

Highlight:

1300nm MPO Fiber Jumper

24F MPO Fiber Jumper

Single Mode MPO Jumper

Product Description

Single Mode Bending Breakout 1300nm 12F 24F MPO Fiber Jumper

Product Overview

MPO breakout fibers singlemode/multimode fiber optic patch cords designed for high-density fiber optic applications. These cables feature MPO to LC breakout configurations with bending insensitive technology for reliable performance in demanding environments.

Application & Maintenance

The maintenance method applies to mapping optical fibers between MPO and LC interfaces. Breakout boxes offer more flexible fiber layout compared to direct MPO-LC fibers, with no restrictions on installation direction - they can be installed positively or negatively as needed.

LC interfaces support automatic dust-proof covers, while MPO interfaces include dustproof plugs for enhanced protection.

Key Features

High fiber density (24 fibers for Multimode)
Low insertion loss and reflection loss
Excellent durability and exchangeability
High temperature stability
Bending insensitive design

Important Usage Note

When using breakout optical fiber, insert the X1 end into a 40GE QSFP+ optical module and the X2 end into four 10GE interfaces. If the 40GE interface is Down but the four 10GE interfaces are Up:

Verify the 40GE interface supports breakout functionality
Check if the 40GE interface is configured in breakout state
Replace with compatible interface if necessary

Technical Specifications

Parameter	Specification
Product Name	12F MPO To LC Breakout Cable SM or 50/125um Aqua
Mode Type	Multimode
Cable Count	8 core (customizable: 4/8/12/16/24/32 core)
Core Type	50/125um
Cable Color	Aqua (customizable)
Cable Diameter	3.0/3.5mm (customizable)
Insertion Loss	≤ 0.5dB
Return Loss	≥25 dB
Wavelength	850/1300nm
Connector Type	Male
Operating Temperature	-40°C to +85°C
Warranty	3 years after delivery

MPO-LC Fiber Structure

Custom Order Options

Connector type: SC / FC / LC / ST / MPO / MTP / MU / MTRJ / E2000 / SMA
Mode type: single mode (UPC and APC) / multi mode (PC)
Cable diameter: 0.9 / 2.0 / 3.0 mm (customizable)
Coating material: PVC / LSZH
Fiber count: simple / duplex / 4 core / 6 core / 8 core / 12 core / 24 core / 48 core / 96 core
Cable type: G652D / G657A1 / G657A2 / G655 / OM1 / OM2 / OM3-150 / OM3-300 / OM4 / OM5
Patch cord length: customizable
MPO/MTP connector: specify method (A type / B type / C type), male/female, fiber count

WHATSAPP: +8613534063703

Frequently Asked Questions

Q: Are you a manufacturer of fiber products?

A: Yes, we are a manufacturer in Shenzhen, China. Our main products include MPO fiber breakout cables, patch cords, pigtails, fiber optical adapters, attenuators, PLC splitters, WDM, and 1U boxes.

Q: What's your MOQ?

A: MOQ can be 1 piece, but we recommend larger quantities for better pricing as single-piece orders incur higher costs.

Q: What's the price?

A: Pricing depends on quantity. We provide competitive pricing for bulk orders upon request with detailed specifications.

Q: Can you quote FOB price?

A: We primarily ship via air couriers (DHL, TNT, UPS, FEDEX). For large shipments, we can provide sea freight options. EXW or CFR pricing is typically more suitable.

Q: How is your quality?

A: We follow IEC and European standards with near dust-free workshop conditions. All products undergo 100% testing before delivery using imported production and quality control equipment.

Q: What's your lead time?

A: We have three factories in China. For fiber optic patch cords, lead time is 2-3 working days for 5000 pieces. Regular products are available from stock.

Q: What's your warranty?

A: Patch cords include 2-year warranty for non-artificial damage. We provide free repair for artificial damage with customer covering freight costs.

Q: What's your packing?

A: We use international export packaging with optional custom logo printing available.

Q: Can you do OEM/ODM?

A: Yes, we accept OEM/ODM orders and can sign Confidentiality Agreements.

Q: Can I have a sample?

A: Free samples available for adapters, attenuators, patch cords, and pigtails with freight prepaid by customer. High-value products require sample charge refundable with order.

Q: How can I order?

A: Send inquiry with product specifications and quantity. We provide quotation, proforma invoice, and arrange production upon payment confirmation.

Q: What are your payment terms?

A: T/T, Western Union, Paypal, MoneyGram. For large orders: 50% deposit, 50% balance before delivery.

Packing Reference
