40G/100G 1300nm MTP Fiber Jumper with Customized Length for High-Speed Structured Cabling

Brand Name:	New Light
Model Number:	MPO -12*LC
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Product Name:

SS-OPMPO12-4*DLCM

Connector Type:

MPO- 8*LC

Core Type:

50/125um

Insertion Loss:

Insertion Loss ≤ 0.5dB

Cable Length:

Customized

Fiber Type:

Fiber Count:

8 FIBER

Jacket:

Cable Diameter:

3.5mm

Cable Color:

MPO Type:

Male Type

Supply Ability:

500 pcs per day

Highlight:

MM MTP Fiber Jumper

1300nm MTP Fiber Jumper

100G MTP Fiber Cable Jumper

Product Description

Structured Cabling 40G 100G 1300nm MM MTP Fiber Jumper

Product Description

MTP® Assemblies fiber jumper specifically designed for laser optimized 40G/100G structured cabling systems employing parallel optics transmission.

For 40G Ethernet, 4Tx and 4Rx fibers are transmitted at 10G for an aggregate of 40G using a 12-fiber MTP® connector. For 100G Ethernet, 10Tx and 10Rx fibers are transmitted at 10G for an aggregate of 100G using a 24-fiber MTP® connector. Alternatively, 100G can utilize two 12-fiber MTP® connectors, though the single port 24-fiber connector is the preferred approach.

Key Features

Most cost-effective solution for 40G/100G transmissions in short reach systems
Pre-terminated 12-fiber or 24-fiber MTP® solutions in customized configurations
Specifically terminated with unique fiber channeling for 40G/100G Ethernet
High density solution within minimal physical space
Supports high bandwidth applications

Important Note

When using breakout optical fiber, insert the X1 end into a 40GE QSFP+ optical module and the X2 end into four 10GE interfaces. If the 40GE interface is Down but the four 10GE interfaces are Up, check the 40GE interface status. Verify that the 40GE interface supports the breakout function and is configured in the breakout state.

Technical Parameters

Parameter	Specification
Product Name	12F MPO To LC Breakout Cable SM or 50/125um Aqua
Mode Type	MM
Cable Count	8 core (can be 4/8/12/16/24/32 core)
Core Type	50/125um
Cable Color	Aqua (customizable)
Cable Diameter	3.0/3.5mm (customizable)
Insertion Loss	≤ 0.5dB
Return Loss	≥25 dB
Wavelength	850/1300nm
Connector Type	Male
Connector Color	Aqua (Aqua/Magenta/Beige available)
Ferrule Material	Plastic
Operating Temperature	-40°C to +85°C
Warranty	3 years after delivery
Delivery Time	2-15 working days (based on quantity)

MPO-LC Fiber Structure

Ordering Information

Connector type: SC/FC/LC/ST/MPO/MTP/MU/MTRJ/E2000/SMA
Mode type: Single mode (UPC and APC) / Multi mode (PC)
Cable diameter: 0.9/2.0/3.0mm (customizable)
Coating material: PVC/LSZH
Fiber count: Simple/Duplex/4 core/6 core/8 core/12 core/24 core/48 core/96 core
Cable type: G652D/G657A1/G657A2/G655/OM1/OM2/OM3-150/OM3-300/OM4/OM5
Patch cord length: Customizable
MPO/MTP connector: Specify method (A type/B type/C type), male/female, fiber count (4/8/12/16/24/32 fiber)

WHATSAPP +8613534063703

Frequently Asked Questions

Q: Are you a manufacturer of fiber products?

A: Yes, we are a manufacturer in Shenzhen, China. Our main products include MTP® Assemblies fiber jumpers, Patch Cords/Pigtails, Fiber Optical Adapters, Attenuators, PLC Splitters, WDM, 1U Boxes, and more.

Q: What's your MOQ?

A: MOQ can be 1 piece, but we recommend larger quantities for better pricing as single-piece orders incur higher costs.

Q: What's the price?

A: Pricing is quantity-dependent. We provide competitive pricing based on your order quantity.

Q: Can you quote FOB price?

A: We primarily ship via air couriers (DHL, TNT, UPS, FEDEX) due to product size. EXW or CFR pricing is preferred. We offer competitive freight solutions for all order sizes.

Q: How is your quality?

A: Our production follows IEC and European standards in near dust-free workshops using imported equipment. All products undergo 100% testing before delivery.

Q: What's your lead time?

A: We operate three factories in China with rapid production capabilities. Standard lead time is 2-3 working days for 5,000 pieces, with stock available for regular products.

Q: What's your warranty?

A: 2-year warranty for patch cords covering non-artificial damage. We provide free repair for artificial damage with customer covering freight costs.

Q: What's your packing?

A: International export packaging with optional custom logo printing available.

Q: Can you do OEM/ODM?

A: Yes, we accept OEM/ODM orders and can sign Confidentiality Agreements.

Q: Can I have a sample?

A: Free samples available for adaptors, attenuators, patch cords, and pigtails with freight prepaid by customer. Sample charges for high-value products are refundable with order placement.

Q: How can I order?

A: Contact us with product specifications and quantity. We'll provide pricing and lead time, then issue a Proforma Invoice upon acceptance. Production begins after payment confirmation.

Q: What are your payment terms?

A: T/T, Western Union, PayPal, MoneyGram. For large orders: 50% deposit, 50% balance before delivery.

Packing Reference
