OM3 OM4 Pre-connector MTP Trunk Cable with 12/24 Fiber and Custom Length Options

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

OM3 OM4 Pre-connector MTP Trunk Cable with 12/24 Fiber and Custom Length Options

Brand Name:	New Light
Model Number:	MPO -12*LC
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Product Name:

MTP® Femaile To Male Trunk Cable

Connector Type:

MPO- 12*LC

Core Type:

50/125um

Insertion Loss:

Insertion Loss ≤ 0.35dB

Cable Length:

Customized

Fiber Type:

Fiber Count:

12/24 FIBER

Jacket:

Cable Diameter:

3.5mm

Cable Color:

MPO Type:

Male Type

Supply Ability:

500 pcs per day

Highlight:

Pre Connector MTP Trunk Cable

Female To Male MTP Trunk Cable

OM4 MTP Trunk Cord

Product Description

OM3 OM4 Pre Connector Female to Male MTP Trunk Cable

Product Description

Pre-connector MTP® Trunk Cable Assemblies consist of 12, 24, or 48 fiber LSZH jacketed micro cables terminated at both ends with MTP® Connectors (without pins). These assemblies serve as backbone or horizontal cable interconnections in data center and networking applications. The plug-and-play design with micro core cable maximizes bend radius while minimizing cable weight and size. Factory pre-terminated, tested, and delivered with test reports, these assemblies are available in OM3, OM4, and single-mode fiber variants. Standard lengths include 5, 10, and 25 meters, with custom lengths available upon request. Packaging options include coils for lengths up to 50m and reels for longer runs. OM3 and OM4 cables feature aqua jackets, while single-mode cables are yellow.

Key Features

Cost-effective solution for 40G/100G short-reach transmission systems
Pre-terminated 12-fiber or 24-fiber MTP® solutions with customizable configurations
Unique fiber channeling specifically designed for 40G/100G Ethernet applications
High-density solution optimized for minimal physical space requirements
Supports high-bandwidth applications with reliable performance

Technical Specifications

Parameter	Specification
Product Name	12F MPO To LC Breakout Cable SM or 50/125um Aqua
Mode Type	Multimode
Cable Count	8 core (customizable: 4/8/12/16/24/32 core)
Core Type	50/125um
Cable Color	Aqua (customizable upon request)
Cable Diameter	3.0/3.5mm (customizable diameters available)
Insertion Loss	≤ 0.5dB
Return Loss	≥25 dB
Wavelength	850/1300nm
Connector Type	Male
Connector Color	Aqua (Aqua/Magenta/Beige available)
Ferrule Material	Plastic
Operating Temperature	-40°C to +85°C
Warranty	3 years after delivery
Delivery Time	2-15 working days (based on quantity)

Custom Order Options

Connector Type: SC, FC, LC, ST, MPO, MTP, MU, MTRJ, E2000, SMA
Mode Type: Single Mode (UPC and APC), Multimode (PC)
Cable Diameter: 0.9mm, 2.0mm, 3.0mm (custom diameters available)
Coating Material: PVC, LSZH
Fiber Count: Simplex, Duplex, 4, 6, 8, 12, 24, 48, 96 cores and more
Cable Type: G652D, G657A1, G657A2, G655, OM1, OM2, OM3-150, OM3-300, OM4, OM5
Patch Cord Length: Customizable to your requirements
MPO/MTP Configuration: Specify method (A/B/C type), gender (male/female), and fiber count

Contact Us: WHATSAPP +8613534063703

Frequently Asked Questions

Q: Are you a manufacturer of fiber products?

A: Yes, we are a manufacturer based in Shenzhen, China. Our product range includes MTP trunk cables, patch cords, pigtails, fiber optic adapters, attenuators, PLC splitters, WDM devices, 1U boxes, and more.

Q: What's your minimum order quantity (MOQ)?

A: MOQ is 1 piece, though we recommend larger quantities for better pricing efficiency.

Q: What's the pricing structure?

A: Pricing varies by quantity. We provide competitive quotes based on your specific requirements and order volume.

Q: Can you provide FOB pricing?

A: While possible, we typically recommend EXW or CFR pricing due to the compact nature of our products, which are often shipped via air carriers like DHL, TNT, UPS, or FedEx.

Q: How do you ensure product quality?

A: Our manufacturing follows IEC and European standards in near dust-free environments. We utilize imported production and quality control equipment, with 100% testing before shipment.

Q: What is your typical lead time?

A: With three specialized factories in China, we can process 5,000 patch cords in 2-3 working days. Standard products are often available from stock, and we accommodate urgent orders.

Q: What warranty do you offer?

A: Patch cords carry a 2-year warranty covering non-artificial damage. We provide free repairs for artificial damage, though shipping costs are the customer's responsibility.

Q: What packaging do you use?

A: We employ international export-standard packaging with optional custom logo printing.

Q: Do you offer OEM/ODM services?

A: Yes, we support full OEM/ODM capabilities and can execute confidentiality agreements.

Q: Can I request samples?

A: Free samples are available for adapters, attenuators, patch cords, and pigtails with customer-paid shipping. Higher-value products may require sample charges, refundable upon order placement.

Q: How do I place an order?

A: Contact us with product specifications and quantity. We'll provide pricing and lead time, then issue a proforma invoice. Production begins after payment confirmation, with tracking provided upon shipment.

Q: What are your payment terms?

A: We accept T/T, Western Union, PayPal, and MoneyGram. For large orders, 50% deposit with balance due before shipment is available.

Packaging Reference
