FTTX SC Simplex LSZH 1m Tight Buffered Fiber Optic Pigtail with 0.9mm Diameter for Indoor Use

Brand Name:	New Light
Model Number:	SC/ UPC
MOQ:	1
Price:	0.2~10
Packaging Details:	OPP bag + carton box
Payment Terms:	L/C,T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE , ISO , RoHS

Products Name:

Tight Buffered Fiber Optic Cable

Connector Type:

SC( Can Be ST , FC , LC , MPO , MTRJ , MU )

Mode Type:

MM ,SM

Cable Color:

Yellow

Cable Diameter:

0.9mm

Cable Length:

1 M (can Be Customized )

Insertion Loss:

≤ 0.3 DB

Return Loss:

≥ 40dB

Delivery Time:

2-7 Working Days

Payment Term:

30% Deposit In Advance , 70% Balance Paid Before Delivery

Supply Ability:

1000000

Highlight:

1m Tight Buffered Optical Cable

LSZH Tight Buffered Optical Cable

FTTX SC Simplex Optic Pigtail

Product Description

FTTX SC Simplex LSZH 1m Tight Buffered Optical Cable

Multimode 12-color SC simplex tight buffered fiber optic cable designed for reliable indoor use and medium-length LAN/WAN connections.

Tight buffered cables offer superior durability for indoor applications and simplify installation with no gel cleanup required. These cables allow direct crimping of connectors to each fiber without needing fan-out kits for splicing or termination.

Contact via WhatsApp: 008613534063703

Key Features

Simplex and Duplex assemblies available
PC and UPC polishing options
Loopback capability
Customized lengths upon request
100% tested before shipping
PVC and LSZH outer sheath options
0.9mm, 2.0mm and 3.0mm cable diameters
Hybrid patch cords available upon request
Fan-out options (Ribbon type / bundle type)

Applications

Telecommunication networks
ODF of optical transmission systems
FTTX FTTH FTTD applications
Data transmission networks
Computer networks (Gigabit Ethernet, SoNet, etc.)
Interconnection of fiber optic transmission equipment

Technical Specifications

Specification	S.M PC	S.M UPC	S.M APC	M.M
Insertion Loss (dB)	≤0.30dB	≤0.20dB	≤0.20dB	≤0.30dB
Return Loss (dB)	≥50dB	≥55dB	≥60dB	-
Durability (1000 matings)	≤0.20dB
Operating Temperature	-40°C to +85°C
Storage Temperature	-40°C to +85°C
Cable Diameter (mm)	0.9/2.0/3.0
Cable Length (m)	1M, 2M, 3M, 5M, Customized

Pigtails are used for splice applications when terminating outside plant cable. They consist of a connector and a special length of fiber for easy termination.

Multimode fiber (MMF) is primarily used for short-distance communication, such as inside buildings or campus environments. With a larger core (typically 50 or 62.5 microns), multimode fiber enables multiple light modes to propagate, allowing more data transmission simultaneously. Maximum transmission distance is approximately 550m at 10Git/s, extending to about 2km at 100Mb/s.

Fiber Optic Pigtail Splicing

Factory-attached connectors ensure high-quality pigtails with greater accuracy than field-terminated cables. Pigtails can be attached via fusion or mechanical splicing. Fusion splicing takes under a minute with proper equipment, significantly reducing installation time and costs. Mechanical splicing provides precise fiber alignment for temporary or permanent connections. Always order extra length to accommodate splicing errors, and select high-quality pigtails for easier installation.

Frequently Asked Questions

Are you the real manufacturer?
Yes, we are the manufacturer with 15 years of experience.
What's the MOQ?
Minimum order quantity for fiber optic cable is 1km.
What's delivery time?
Standard delivery is 5-7 days after order confirmation, depending on quantity.
How to Store the Optical Fiber Cable Properly?
Store drums indoors, placed sideways rather than on end.
Can you supply customized products and logo?
Yes, we provide OEM service. Please send your specifications.
What's your payment terms?
We accept T/T, L/C, Western Union, D/P with 30% advance and 70% before shipment.

Payment Terms & Delivery

Payment Methods: T/T, L/C, PayPal, Western Union, MoneyGram
Payment Terms: 30% deposit in advance, 70% balance paid before delivery
Packaging: International standard packaging (OPP bag + Carton Box)
Delivery Time: 2-7 working days after payment receipt (depending on quantity)
Warranty: 3 years after delivery
Shipping Methods: By air (DHL, TNT, UPS, FedEx) or by sea (as required)
