G657A1 9/125um 1550nm Fiber Optic Patch Cord for FTTH FTTB Networks

Brand Name:	New Light
Model Number:	LC-SC
MOQ:	1~100000
Price:	0.1~100
Packaging Details:	opp bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Product Name:

LC APC 8 Degree Polishing Armoured Fiber Optic Patch Cord Sc Lc

Connector:

SC UPC- LC APC

Fiber Type:

Simplex

Length:

Any Length

Insertion Loss:

≤0.3dB

Wavelength:

1310nm / 1550nm

Quality Control:

100% Test Before Shipping

Return Loss:

≥50dB

Polish:

UPC And APC

Real Factory:

Application:

FTTH FTTB FTTX Network

Supply Ability:

1000000

Highlight:

FTTB Fiber Optic Patch Cord

G657A1 Fiber Optic Patch Cord

1550nm Fiber Optic Patch Cable

Product Description

9/125um FTTB G657A1 Fiber Optic Patch Cord 1550nm

LSH/APC 8° Simplex 9/125um G657A1 Fiber Optic Patch Cord

These fiber optic patch cords are engineered to support high-speed telecommunication network applications. Manufactured and tested in compliance with TIA 604 (FOCIS), IEC 61754, and YD/T industry standards, they are available in OM1, OM2, OM3, OM4, OM5, and OS2 fiber types to meet the demands of Gigabit Ethernet, 10 Gigabit Ethernet, and high-speed Fiber Channel networks. Every termination undergoes rigorous parameter testing to ensure optimal network performance.

Standards Compliance

RoHS, ISO 9001 Compliant
TIA 604 (FOCIS)
TIA/EIA 492AAAE
IEC 61754
IEC 60793-2-10
IEC 61300-3-35
YD/T1272.1-2003

Key Features

High quality zirconia ferrules
Excellent repeatability and interchangeability
Available connector types: LC, SC, ST, FC, LSH, MTRJ, MU
Flame-retardant, rugged and durable jacket
Clear printing for easy cable identification
Available fiber types: OS2, OM4, OM3, OM2, OM1, OM5
Factory terminated and tested for insertion loss, return loss, and end face quality

Technical Specifications

Physical Characteristics

Parameter	Description
Connector Types End A	LC/SC/ST/FC/LSH/MU/MTRJ
Connector Types End B	LC/SC/ST/FC/LSH/MU/MTRJ
Polish Type	SMF: UPC-UPC; UPC-APC; APC-UPC; APC-APC; MMF: UPC-UPC
Connector Ferrule	Zirconia Ceramic
Cable Diameter	Duplex: 2.0/3.0mm; Simplex: 0.9/2.0/3.0mm
Interchangeability	≤ 0.2dB
Minimum Bend Radius	SMF: 10mm; MMF: 7.5mm/15mm

Mechanical Characteristics

Parameter	Description
Fiber Type	OS2/OM5/OM4/OM3/OM2/OM1
Fiber Count	Duplex/Simplex
Cable Jacket	PVC (Riser/OFNR)/LSZH/Plenum (OFNP)
Jacket Color	OM1/OM2: Orange; OM3/OM4: Aqua; OM5: Lime Green; OS2: Yellow
Fiber Grade	OM5/OM4/OM3/OM2: Bend Insensitive; OM1: G.651

Optical Characteristics

Parameter	Specification
Connector Insertion Loss	LC/SC/ST/FC/LSH/MU/MTRJ ≤ 0.3dB
Connector Return Loss	SMF: UPC≥50, APC≥60 (LC/SC/ST/FC/MU/MTRJ), UPC≥55, APC≥75 (LSH) MMF: UPC≥30 (LC/SC/ST/FC/LSH/MU), UPC≥35 (MTRJ)
Attenuation at 1310nm	0.36dB/km
Attenuation at 1550nm	0.22dB/km
Attenuation at 850nm	3.0dB/km
Attenuation at 1300nm	1.0dB/km

Environmental Characteristics

Parameter	Specification
Operating Temperature	-20°C to 70°C
Storage Temperature	-40°C to 80°C

Hot Sale Products

How to Order Optical Fiber Patch Cord

Connector type: SC / FC / LC / ST / MPO / MTP / MU / MTRJ / E2000 / SMA
Mode type: single mode (UPC and APC) / multi mode (PC)
Cable diameter: 0.9 / 2.0 / 3.0 mm (custom diameters available)
Coating material: PVC / LSZH
Fiber count: simplex / duplex / 4 core / 6 core / 8 core / 12 core / 24 core / 48 core / 96 core and more
Cable type: G652D / G657A1 / G657A2 / G655 / OM1 / OM2 / OM3-150 / OM3-300 / OM4 / OM5
Patch cord length: customized to your requirements
For MPO/MTP connectors: specify method (A type / B type / C type), male or female, fiber count (4/8/12/16/24/32 fiber)

Frequently Asked Questions

Q: Are you a manufacturer?

A: Yes, we are a manufacturer located in Shenzhen, China.

Q: What's your MOQ?

A: MOQ can be 1 piece, but we don't recommend ordering single pieces as the cost and price will be higher than your budget.

Q: What's the price?

A: Pricing depends on quantity. We provide our best pricing based on your order quantity, with competitive rates for larger volumes.

Q: Can you quote FOB price?

A: Yes, but due to small size and weight, most deliveries are by air (DHL, TNT, UPS, FEDEX). For large quantities with multiple cartons, we can provide sea freight options. EXW or CFR pricing is typically better.

Q: How is your quality?

A: We produce according to IEC and European standards in near dust-free workshops using imported production and quality control equipment. All products are 100% tested before delivery.

Q: What's your lead time?

A: We have three factories in China. For fiber optic patch cords, lead time is 2-3 working days for 5000 pieces. Regular products are in stock, and we can accommodate urgent orders.

Q: What's your warranty?

A: Patch cords come with a 2-year warranty for non-artificial damage. For artificial damage, we provide free repairs with freight paid by customer.

Q: What's your packing?

A: We use international export packaging and can print your logo on the packaging.

Q: Can you do OEM/ODM?

A: Yes, we accept OEM/ODM orders and can sign Confidentiality Agreements.

Q: Can I have a sample?

A: Free samples available for adaptors, attenuators, patch cords, and pigtails with freight prepaid by customer. For high-value products, sample charges apply but are refunded upon order placement.

Q: How can I order?

A: Send us your product requirements, specifications, and quantity. We'll provide pricing and lead time, then issue a Proforma Invoice upon acceptance. Production begins after payment confirmation.

Q: What are your payment terms?

A: T/T, Western Union, Paypal, MoneyGram. For large amounts: 50% deposit, 50% balance before delivery.

Packaging Reference
