OS2 Single Mode LC/APC Fiber Patch Cable for FTTX Network Applications

Brand Name:	New Light
Model Number:	LC-SC
MOQ:	1~100000
Price:	0.1~100
Packaging Details:	opp bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Product Name:

Optical Fibre Patch Cords

Connector:

LC UPC- LC APC

Fiber Type:

Duplex

Length:

Any Length

Insertion Loss:

≤0.3dB

Wavelength:

1310nm / 1550nm

Quality Control:

100% Test Before Shipping

Return Loss:

≥50dB

Polish:

UPC And APC

Real Factory:

Application:

FTTH FTTB FTTX Network

Supply Ability:

1000000

Highlight:

FTTX Fiber Patch Cables

FO Fiber Patch Cables

OS2 Single Mode Optical Cable

Product Description

FTTX OS2 LC/APC FO Fiber Patch Cables OS2 Single Mode

OS2 single mode E9/125 LC/APC FO Standard Fiber Patch Cables are designed for cross-connecting installed cables and connecting communications equipment to the cable plant. Proper patch cord selection is critical for optimal network performance.

Network Performance Considerations

The performance of fiber optic networks can be compromised by improper patch cord selection. Ensure fiber type matches your cable plant: use 50/125 patchcords with 50/125 fibers, 62.5/125 with 62.5/125 fibers. While exact fiber type matching isn't always required (OM3 patchcords work with OM2 or OM4 cable plants), singlemode fibers with different mode field diameters should use matching patchcords.

Application Range

Indoor LAN connections
Data Centers distributor cabinet

Product Features

Flame-retardant, halogen-free outer sheath
High flexibility with durable ceramic ferrules
Pre-assembled connectors with low insertion loss and high return loss
High quality zirconia ferrules
Excellent repeatability and interchangeability
Available connector types: LC, SC, ST, FC, LSH, MTRJ, MU
Flame-retardant, rugged and durable jacket
Clear printing for cable identification
Available fiber types: OS2, OM4, OM3, OM2, OM1, OM5
Factory terminated and tested for insertion loss, return loss and end face quality

Technical Specifications

Physical Characteristics

Parameter	Description
Connector Types End A	LC/SC/ST/FC/LSH/MU/MTRJ
Connector Types End B	LC/SC/ST/FC/LSH/MU/MTRJ
Polish type	SMF: UPC-UPC; UPC-APC; APC-UPC; APC-APC; MMF: UPC-UPC
Connector Ferrule	Zirconia Ceramic
Cable Diameter	Duplex: 2.0/3.0mm; Simplex: 0.9/2.0/3.0mm
Interchangeability	≤ 0.2dB
Minimum Bend Radius	SMF: 10mm; MMF: 7.5mm/15mm

Mechanical Characteristics

Parameter	Description
Fiber type	OS2/OM5/OM4/OM3/OM2/OM1
Fiber count	Duplex / Simplex
Cable Jacket	PVC (Riser/OFNR)/LSZH/Plenum (OFNP)
Jacket Color	OM1/OM2: Orange; OM3/OM4: Aqua; OM5: Lime Green; OS2: Yellow
Fiber Grade	OM5/OM4/OM3/OM2: Bend Insensitive; OM1: G.651

Optical Characteristics

Parameter	Specification
Connector Insertion Loss	LC/SC/ST/FC/LSH/MU/MTRJ ≤ 0.3dB
Connector Return Loss	SMF: UPC≥50, APC≥60 (LC/SC/ST/FC/MU/MTRJ), UPC≥55, APC≥75 (LSH) MMF: UPC≥30 (LC/SC/ST/FC/LSH/MU), UPC≥35 (MTRJ)
Attenuation at 1310nm	0.36dB/km
Attenuation at 1550nm	0.22dB/km
Attenuation at 850nm	3.0dB/km
Attenuation at 1300nm	1.0dB/km

Environmental Characteristics

Parameter	Specification
Operating Temperature	-20°C to 70°C
Storage Temperature	-40°C to 80°C

Ordering Information

When ordering Optical Fibre Patch Cords, please specify the following parameters:

Connector type: SC / FC / LC / ST / MPO / MTP / MU / MTRJ / E2000 / SMA
Mode type: single mode (UPC and APC) / multi mode (PC)
Cable diameter: 0.9 / 2.0 / 3.0 mm (custom diameters available)
Coating material: PVC / LSZH
Fiber count: simplex / duplex / 4 core / 6 core / 8 core / 12 core / 24 core / 48 core / 96 core
Cable type: G652D / G657A1 / G657A2 / G655 / OM1 / OM2 / OM3-150 / OM3-300 / OM4 / OM5
Patch cord length: according to your requirements
For MPO/MTP connectors: specify method (A type / B type / C type), male/female, and fiber count (4/8/12/16/24/32 fiber)

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer located in Shenzhen, China.

What's your MOQ?

MOQ can be 1 piece, but we don't recommend ordering single pieces due to higher costs.

What's the price?

Pricing depends on quantity. We provide competitive pricing for larger quantities.

Can you quote FOB price?

Yes, but most shipments are via air freight. We recommend EXW or CFR pricing for better solutions.

How is your quality?

We follow IEC and European standards with imported production equipment. All products are 100% tested before delivery.

What's your lead time?

We have three factories in China. For fiber optic patch cords, lead time is 2-3 working days for 5000 pieces.

What's your warranty?

2-year warranty for non-artificial damage. Artificial damage repairs are free, but freight is customer's responsibility.

What's your packing?

International export packaging with optional logo printing available.

Can you do OEM/ODM?

Yes, we accept OEM/ODM and can sign Confidentiality Agreements.

Can I have a sample?

Free samples available for adaptors, attenuators, patch cords, and pigtails (freight paid by customer).

How can I order?

What are your payment terms?

T/T, Western Union, Paypal, MoneyGram. For large amounts: 50% deposit, 50% balance before delivery.
