3M OM3 Duplex SC UPC-LC APC LSZH OFNR Optical Fiber Patch Cord for FTTH FTTB FTTX Networks

Brand Name:	New Light
Model Number:	LC-SC
MOQ:	1~100000
Price:	0.1~100
Packaging Details:	opp bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Product Name:

FOA Patch Cables

Connector:

SC UPC- LC APC

Fiber Type:

Duplex

Length:

Any Length

Insertion Loss:

≤0.3dB

Wavelength:

1310nm / 1550nm

Quality Control:

100% Test Before Shipping

Return Loss:

≥50dB

Polish:

UPC And APC

Real Factory:

Application:

FTTH FTTB FTTX Network

Supply Ability:

1000000

Highlight:

LSZH Optic Fibre Patch Cord

OFNR Optic Fibre Patch Cord

OM3 Duplex Patch Cord

Product Description

3M OM3 Duplex SC OFNR LSZH Optic Fibre Patch Cord FTTH

The 3M OM3 duplex OFNR/LSZH SC connector optic fibre patchcord is engineered for high-performance fiber optic connectivity. Constructed with a core featuring high refractive index surrounded by a low refractive index coating, strengthened by aramid yarns and protected by a durable jacket, this patch cord ensures minimal signal loss over extended distances. The coating's reflective properties maintain signal integrity while the protective layers safeguard against physical damage.

Key Features

Low insertion loss for optimal signal transmission
High return loss performance
Excellent repeatability and interchangeability
Superior environmental adaptability
Compliant with industry standards including IEC 61754-20 (LC) and IEC 61754-4 (SC)

Technical Specifications

Physical Characteristics

Parameter	Specification
Connector Types End A	LC/SC/ST/FC/LSH/MU/MTRJ
Connector Types End B	LC/SC/ST/FC/LSH/MU/MTRJ
Polish Type	SMF: UPC-UPC; UPC-APC; APC-UPC; APC-APC; MMF: UPC-UPC
Connector Ferrule	Zirconia Ceramic
Cable Diameter	Duplex: 2.0/3.0mm; Simplex: 0.9/2.0/3.0mm
Interchangeability	≤ 0.2dB
Minimum Bend Radius	SMF: 10mm; MMF: 7.5mm/15mm

Mechanical Characteristics

Parameter	Specification
Fiber Type	OS2/OM5/OM4/OM3/OM2/OM1
Fiber Count	Duplex/Simplex
Cable Jacket	PVC (Riser/OFNR)/LSZH/Plenum (OFNP)
Jacket Color	OM1/OM2: Orange; OM3/OM4: Aqua; OM5: Lime Green; OS2: Yellow
Fiber Grade	OM5/OM4/OM3/OM2: Bend Insensitive; OM1: G.651

Optical Characteristics

Parameter	Specification
Connector Insertion Loss	LC/SC/ST/FC/LSH/MU/MTRJ ≤ 0.3dB
Connector Return Loss	SMF: UPC≥50, APC≥60 (LC/SC/ST/FC/MU/MTRJ), UPC≥55, APC≥75 (LSH) MMF: UPC≥30 (LC/SC/ST/FC/LSH/MU), UPC≥35 (MTRJ)
Attenuation at 1310nm	0.36dB/km
Attenuation at 1550nm	0.22dB/km
Attenuation at 850nm	3.0dB/km
Attenuation at 1300nm	1.0dB/km

Environmental Characteristics

Parameter	Specification
Operating Temperature	-20°C to 70°C
Storage Temperature	-40°C to 80°C

Ordering Information

To order your optical fibre patch cords, please specify the following parameters:

Connector type: SC / FC / LC / ST / MPO / MTP / MU / MTRJ / E2000 / SMA
Mode type: Single mode (UPC and APC) / Multi mode (PC)
Cable diameter: 0.9 / 2.0 / 3.0 mm (custom diameters available)
Coating material: PVC / LSZH
Fiber count: Simplex / Duplex / 4 core / 6 core / 8 core / 12 core / 24 core / 48 core / 96 core
Cable type: G652D / G657A1 / G657A2 / G655 / OM1 / OM2 / OM3-150 / OM3-300 / OM4 / OM5
Patch cord length: Customized to your requirements
For MPO/MTP connectors: Specify method (A type / B type / C type), gender (male/female), and fiber count (4/8/12/16/24/32 fiber)

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer based in Shenzhen, China.

What's your MOQ?

MOQ can be 1 piece, though we recommend larger quantities for better pricing.

What's the price?

Pricing varies by quantity. Contact us with your requirements for competitive quotes.

Can you quote FOB price?

We primarily ship via air couriers. For large orders, we can provide sea freight options. EXW or CFR pricing is typically preferred.

How is your quality?

We adhere to IEC standards with imported production equipment and 100% testing before delivery.

What's your lead time?

Regular products: 2-3 working days for 5,000 pieces. We maintain stock for standard items and accommodate urgent orders.

What's your warranty?

2-year warranty for non-artificial damage. Free repair service for artificial damage (customer pays freight).

What's your packing?

International export packaging with optional custom logo printing available.

Can you do OEM/ODM?

Yes, we accept OEM/ODM orders and can sign confidentiality agreements.

Can I have a sample?

Free samples available for patch cords, adaptors, and attenuators (customer pays freight). Sample charges apply for high-value products but are refundable with order placement.

How can I order?

Submit inquiry with product specifications and quantity
Receive quotation with lead time
Confirm order and receive proforma invoice
Make payment to initiate production
Receive tracking information upon shipment

What are your payment terms?

T/T, Western Union, Paypal, MoneyGram. For large orders: 50% deposit, 50% balance before delivery.

For detailed specifications, custom requirements, or volume pricing, please contact our technical sales team for personalized assistance.
