Outdoor LSZH OM3 Fiber Optic Patch Cable for FTTH FTTB FTTX Networks

Brand Name:	New Light
Model Number:	FC-SC
MOQ:	1~100000
Price:	0.1~100
Packaging Details:	opp bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Product Name:

FO Patch Cables

Connector:

SC UPC- LC APC

Fiber Type:

Duplex

Length:

Any Length

Insertion Loss:

≤0.3dB

Wavelength:

1310nm / 1550nm

Quality Control:

100% Test Before Shipping

Return Loss:

≥50dB

Polish:

UPC And APC

Real Factory:

Application:

FTTH FTTB FTTX Network

Product Name:

FO Patch Cables

Connector:

SC UPC- LC APC

Fiber Type:

Duplex

Length:

Any Length

Insertion Loss:

≤0.3dB

Wavelength:

1310nm / 1550nm

Quality Control:

100% Test Before Shipping

Return Loss:

≥50dB

Polish:

UPC And APC

Real Factory:

Application:

FTTH FTTB FTTX Network

Supply Ability:

1000000

Highlight:

OFNR Fiber Optic Patch Cable

OM3 Fiber Optic Patch Cable

LSZH Outdoor Duplex Patch Cord

Product Description

OFNR LSZH SC OM3 Fiber Optic Patch Cable Outdoor Duplex

Telegärtner's 3M OM3 duplex OFNR/LSZH SC outdoor fiber optic patch cable enables easy and economical integration of outdoor devices into data networks. These weather-proof, water-tight, and UV-resistant cables feature LC duplex connectors and are available in lengths from 10 to 150 meters.

Key Applications

Ideal for connecting mobile radio base stations, microwave links, IP cameras, gatekeeper houses, and display panels where link lengths exceed the 90-meter copper cable limit recommended by EN 50173.

Performance Features

Low insertion loss
High return loss
Excellent repeatability
Superior interchangeability
Outstanding environmental adaptability

Comprehensive Outdoor Component Range

Connect devices directly to outlets and patch panels with weather-proof, water-tight connectors from our extensive TOC outdoor portfolio, including TDC, FXC, RBC, FEM housings, and IP68-rated metal housings.

Standards Compliance

LC connectors comply with IEC 61754-20
SC connectors comply with IEC 61754-4

Technical Specifications

Physical Characteristics

Parameter	Specification
Connector Types End A/B	LC/SC/ST/FC/LSH/MU/MTRJ
Polish Type	SMF: UPC-UPC; UPC-APC; APC-UPC; APC-APC; MMF: UPC-UPC
Connector Ferrule	Zirconia Ceramic
Cable Diameter	Duplex: 2.0/3.0mm; Simplex: 0.9/2.0/3.0mm
Interchangeability	≤ 0.2dB
Minimum Bend Radius	SMF: 10mm; MMF: 7.5mm/15mm

Mechanical Characteristics

Parameter	Specification
Fiber Type	OS2/OM5/OM4/OM3/OM2/OM1
Fiber Count	Duplex/Simplex
Cable Jacket	PVC (Riser/OFNR)/LSZH/Plenum (OFNP)
Jacket Color	OM1/OM2: Orange; OM3/OM4: Aqua; OM5: Lime Green; OS2: Yellow
Fiber Grade	OM5/OM4/OM3/OM2: Bend Insensitive; OM1: G.651

Optical Characteristics

Parameter	Specification
Connector Insertion Loss	LC/SC/ST/FC/LSH/MU/MTRJ ≤ 0.3dB
Connector Return Loss	SMF: UPC≥50, APC≥60 (LC/SC/ST/FC/MU/MTRJ), UPC≥55, APC≥75 (LSH) MMF: UPC≥30 (LC/SC/ST/FC/LSH/MU), UPC≥35 (MTRJ)
Attenuation at 1310nm	0.36dB/km
Attenuation at 1550nm	0.22dB/km
Attenuation at 850nm	3.0dB/km
Attenuation at 1300nm	1.0dB/km

Environmental Characteristics

Parameter	Specification
Operating Temperature	-20°C to 70°C
Storage Temperature	-40°C to 80°C

Ordering Information

When ordering, please specify the following parameters:

Connector type: SC/FC/LC/ST/MPO/MTP/MU/MTRJ/E2000/SMA
Mode type: Single mode (UPC and APC) / Multi mode (PC)
Cable diameter: 0.9/2.0/3.0mm (custom diameters available)
Coating material: PVC/LSZH
Fiber count: Simplex/Duplex/4 core/6 core/8 core/12 core/24 core/48 core/96 core
Cable type: G652D/G657A1/G657A2/G655/OM1/OM2/OM3-150/OM3-300/OM4/OM5
Patch cord length: Custom lengths available
For MPO/MTP connectors: Specify method (A/B/C type), gender, and fiber count

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer located in Shenzhen, China.

What's your MOQ?

MOQ can be 1 piece, but we recommend larger quantities for better pricing.

What's the price?

Pricing varies by quantity. Contact us with your requirements for competitive pricing.

Can you quote FOB price?

We typically ship via air courier. EXW or CFR pricing is preferred for most orders.

How is your quality?

We follow IEC standards with imported production equipment and 100% testing before delivery.

What's your lead time?

2-3 working days for 5,000 pieces. Regular products are in stock for urgent orders.

What's your warranty?

2-year warranty for non-artificial damage. Free repair for artificial damage (customer pays freight).

What's your packing?

International export packaging with optional logo printing available.

Can you do OEM/ODM?

Yes, we accept OEM/ODM orders and can sign confidentiality agreements.

Can I have a sample?

Free samples available for adaptors, attenuators, patch cords, and pigtails (customer pays freight).

How can I order?

What are your payment terms?

T/T, Western Union, PayPal, MoneyGram. For large orders: 50% deposit, 50% balance before delivery.
