Outdoor FTTA OM2 Multimode Fiber Optic Patch Cord with LC/PC Connector for High-Speed Data Transmission

Brand Name:	New Light
Model Number:	FC-SC
MOQ:	1~100000
Price:	0.1~100
Packaging Details:	opp bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Product Name:

FO Patch Cables

Connector:

SC UPC- LC APC

Fiber Type:

Duplex

Length:

Any Length

Insertion Loss:

≤0.3dB

Wavelength:

1310nm / 1550nm

Quality Control:

100% Test Before Shipping

Return Loss:

≥50dB

Polish:

UPC And APC

Real Factory:

Application:

FTTH FTTB FTTX Network

Supply Ability:

1000000

Highlight:

FTTA Multimode Duplex Cable

OM2 Multimode Duplex Cable

LC/PC Multimode Fo Patch Cord

Product Description

Outdoor FTTA OM2 Multimode Duplex Cable 2G 50/125 LC/PC

FTTA Duplex Cable 2G 50/125 OM2 multimode 2x LC/PC fiber optic patch cord designed for outdoor applications.

Key Features

Optimized kink and crush resistance for demanding environmental conditions
Operating temperature range: -10°C to +60°C (other ranges available upon request)
Multiple coding options: Full-duplex cables with crossed duplex connectors per ISO/IEC 11801 and EN 50173 standards, Half-duplex with uncrossed connectors, Duplex with uncrossed simplex connectors

Outdoor Component Range

These outdoor patch cords enable direct connections between devices, outlets, and patch panels. For applications requiring weather-proof and water-tight connectors, choose from our comprehensive TOC outdoor connector portfolio featuring TDC, FXC, RBC, and FEM housings – including the proven IP68-rated metal housing.

Standards Compliance

LC connectors comply with IEC 61754-20
SC connectors comply with IEC 61754-4

Technical Specifications

Physical Characteristics

Parameter	Specification
Connector Types End A	LC/SC/ST/FC/LSH/MU/MTRJ
Connector Types End B	LC/SC/ST/FC/LSH/MU/MTRJ
Polish Type	SMF: UPC-UPC; UPC-APC; APC-UPC; APC-APC; MMF: UPC-UPC
Connector Ferrule	Zirconia Ceramic
Cable Diameter	Duplex: 2.0/3.0mm; Simplex: 0.9/2.0/3.0mm
Interchangeability	≤ 0.2dB
Minimum Bend Radius	SMF: 10mm; MMF: 7.5mm/15mm

Mechanical Characteristics

Parameter	Specification
Fiber Type	OS2/OM5/OM4/OM3/OM2/OM1
Fiber Count	Duplex / Simplex
Cable Jacket	PVC (Riser/OFNR)/LSZH/Plenum (OFNP)
Jacket Color	OM1/OM2: Orange; OM3/OM4: Aqua; OM5: Lime Green; OS2: Yellow
Fiber Grade	OM5/OM4/OM3/OM2: Bend Insensitive; OM1: G.651

Optical Characteristics

Parameter	Specification
Connector Insertion Loss	LC/SC/ST/FC/LSH/MU/MTRJ ≤ 0.3dB
Connector Return Loss	SMF: UPC≥50, APC≥60 (LC/SC/ST/FC/MU/MTRJ), UPC≥55, APC≥75 (LSH) MMF: UPC≥30 (LC/SC/ST/FC/LSH/MU), UPC≥35 (MTRJ)
Attenuation at 1310nm	0.36dB/km
Attenuation at 1550nm	0.22dB/km
Attenuation at 850nm	3.0dB/km
Attenuation at 1300nm	1.0dB/km

Environmental Characteristics

Parameter	Specification
Operating Temperature	-20°C to +70°C
Storage Temperature	-40°C to +80°C

Ordering Information

When ordering optical fiber patch cords, please specify the following parameters:

Connector type: SC / FC / LC / ST / MPO / MTP / MU / MTRJ / E2000 / SMA
Mode type: Single mode (UPC and APC) / Multi mode (PC)
Cable diameter: 0.9 / 2.0 / 3.0 mm (custom diameters available)
Coating material: PVC / LSZH
Fiber count: Simplex / Duplex / 4 core / 6 core / 8 core / 12 core / 24 core / 48 core / 96 core
Cable type: G652D / G657A1 / G657A2 / G655 / OM1 / OM2 / OM3-150 / OM3-300 / OM4 / OM5
Patch cord length: Custom length according to your requirements
For MPO/MTP connectors: Specify method (A type / B type / C type), gender (male/female), and fiber count (4/8/12/16/24/32 fiber)

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer located in Shenzhen, China.

What's your MOQ?

MOQ can be 1 piece, but we don't recommend ordering single units as the cost per unit will be higher than your budget expectations.

What's the price?

Pricing depends on quantity. After you specify your quantity requirements, we will provide our best pricing. Larger quantities receive more competitive pricing.

Can you quote FOB price?

Yes, but due to the small size and weight of these products, most shipments are delivered by air (DHL, TNT, UPS, FEDEX). We recommend providing detailed specifications and quantity for a complete freight-included price quote. For large volume orders with multiple cartons, we can provide sea freight options. EXW or CFR pricing may be more suitable.

How is your quality?

Our production follows IEC and European standards in near dust-free workshop conditions. We use imported production and quality control equipment, especially for MTP Daisi equipment. All products undergo 100% testing before delivery.

What's your lead time?

We operate three factories in China specializing in fiber optic cable production, patch cords, PLC, ODF, adaptors, and attenuators. For fiber optic patch cords, lead time is 2-3 working days for 5,000 pieces. Regular products are available from stock, and we can accommodate urgent orders.

What's your warranty?

Patch cords carry a 2-year warranty from delivery date covering non-artificial damage. For artificial damage, we provide free repair services with freight costs covered by the customer.

What's your packing?

We use international export packaging and can print your logo on packaging upon request.

Can you do OEM/ODM?

Yes, as a manufacturer we accept all OEM/ODM requests and can sign confidentiality agreements.

Can I have a sample?

Free samples are available for adaptors, attenuators, patch cords, and pigtails with freight prepaid by customer. For higher-value products, sample charges and freight apply upfront, with sample charges refunded upon order placement.

How can I order?

Contact us via email or inquiry with product name, detailed specifications, quantity, and delivery address for freight calculation
We provide best pricing and lead time based on your quantity requirements
Upon acceptance, we issue a Proforma Invoice with bank account details
Production begins after payment receipt
We confirm shipping information and provide tracking number after delivery
We prioritize long-term cooperation and customer requirements

What are your payment terms?

T/T, Western Union, Paypal, MoneyGram. For large orders: 50% deposit in advance, 50% balance before delivery.
