3dB SC FC UPC Fiber Optic Attenuator Single Mode Male to Female for Telecommunication

Brand Name:	New Light
MOQ:	10
Price:	1~30
Packaging Details:	10pcs per pack
Payment Terms:	T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Color:

Green / Red

Connector:

SC FC

Polish:

UPC / APC

Mode:

Single Mode

Attenuator:

3dB

Material:

Metal

Supply Ability:

10000/month

Highlight:

3dB SC Optical Fiber Attenuator

FC UPC Optical Fiber Attenuator

IEC Single Mode Fiber Attenuator

Product Description

3dB SC FC UPC Optical Fiber Attenuator Male To Female IEC Single Mode

This 3dB SC FC UPC Fiber Optic Attenuator (Male to Female) is designed for telecommunications applications, providing precise signal attenuation to maintain optimal optical power levels.

Product Overview

As an optical passive device, this attenuator is primarily used for debugging optical power performance, calibrating optical instruments, and attenuating fiber signals to ensure stable and desired optical power levels in transmission links without altering the original waveform.

Key Features

Low insertion loss and back reflection loss
High precision mechanical dimensions
Compliant with Telcordia GR-326-Core, IEC, TIA standards
RoHS compliant

WHATSAPP: 008613534063703

Technical Specifications

Parameter	Specification
Attenuation Value	Standard: PC 0dB to 20dB (1dB step) APC: 25dB Custom: Step to be specified
Operating Wavelength	1260nm~1620nm
Return Loss	SPC≥40dB UPC≥50dB APC≥60dB
Attenuation Tolerance	Standard: 0dB~10dB ±1.0dB Custom: 11dB~25dB ±1.5dB
Maximum Power Capability	250mW
Operating Temperature	-40℃~+75℃

Custom configurations available upon request

Overall Performance

Fiber optic attenuators are used in applications where a pre-determined amount of light loss is specified. We offer LC, FC, SC, ST, MU fixed attenuators with different attenuation levels from 1dB to 30dB.

Parameter	Specification
Attenuation Value	0dB to 30dB
Operating Wavelength	SM: 1260nm~1620nm, MM: 850/1300nm (Customer ordered)
Return Loss	UPC≥50dB, APC≥60dB
Polarization Loss	≤0.2dB
Attenuation Tolerance	0dB~9dB: 0.5dB, 10~30dB: 10% of attenuation value
Maximum Power Capability	250mW
Operating Temperature	-40°C~+85°C
Storage Temperature	-40°C~+85°C

Applications

Power management in optical networks
Wavelength division multiplexing (WDM) system channel balancing
Erbium Doped Fiber Amplifiers (EDFA)
Optical add-drop multiplexers (OADM)
Receiver protection
Test equipment
Compensation of different connector attenuation

Frequently Asked Questions

Are you the real factory?

Yes, we are the real factory with 16 years of manufacturing history.

What is your fiber brand?

Fiber brands include YOFC and FiberHome.

What are your main products?

Fiber optic patch panels, fiber MPO & MTP cassettes, MPO & MTP cables, outdoor fiber optic cables, indoor fiber optic cables, FTTH drop cables, ADSS cables, indoor armored patch cords, and optical patch cords (SC, LC, FC, ST, MTP, MPO).

What is your product quality guarantee period?

20 years guarantee for fiber optic cable.

Do you have certificates for raw materials?

We maintain long-term relationships with qualified ISO9001 ROHS raw material suppliers.

What is your delivery time?

Within 48 hours for normal types of fiber optic products.

What is your minimum order quantity (MOQ)?

MOQ for Fiber Optic Cable Patch Panel: 10 sets. No MOQ required for fiber optic patch cords as we maintain stock for normal types.

Do you have distributors in other countries?

Currently we sell our products directly to customers and offer factory pricing.

What payment methods do you accept?

For large orders: T/T. For small orders: T/T and PayPal are acceptable.

What are your shipping and delivery options?

For large orders: by sea (LCL or FCL). For small orders: by sea (LCL), by air, or by courier services - any of which is optional.
