1m LSZH 12 Strand Single Mode Fiber Optic Pigtail Cable with FC UPC/APC Connector

Brand Name:	New Light
Model Number:	SC / E2000 / FC / ST
MOQ:	1
Price:	0.2~10
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE , ISO , RoHS

Connector Type:

SC / E2000 / FC / ST

Mode Type:

SM / MM

Cable Diameter:

0.6mm Or 0.9mm

Insertion Loss:

≤0.25dB

Return Loss:

APC≥65dB; PC≥55

Delivery Time:

2-7 Working Days

Supply Ability:

1000000

Highlight:

UPC APC Fiber Optic Cable

12 Strand Fiber Optic Cable

1m fiber optic tail

Product Description

Single Mode Fiber Optic Cable 1m LSZH 0.9mm FC UPC/APC 12 Strand

Product Overview

1-meter LSZH 0.9mm FC UPC/APC 12 strand single mode fiber optic cable designed for high-performance optical communication applications.

Key Features

Insert-pull, key-oriented coupling mechanism for high repeatable, low-loss connections
Simplex, Duplex and Multi-core accessories for standard or customized structures
PC/UPC/APC polish options available
Complies with Telcordia GR-326-CORE Specification
Plastic plug material meets UL94V-0 and RoHS standards

Applications

Optical communication networks
Telecom networks
Ethernet networks
CATV networks

Technical Specifications

Fiber Count	12	Fiber Mode	9/125μm
Connector Type1	LC	Connector Type2	Unterminated
Fiber Mode	SM	Breakout Length	1.5m
Wavelength	1310/1550nm	Jacket Material	PVC/LSZH
Insertion Loss	≤ 0.25dB	Interchangeability	≤0.2dB
Return Loss	≥ 50dB	Vibration	≤0.2dB
Operating Temperature	-40~75°C	Storage Temperature	-45~85°C

Geometric Specifications

Type	Vertex Offset (μm)	Curvature Radius (mm)	Fiber Height (nm)	Angle Offset (°)
2.5mm UPC	≤50	10~25	(-50, +50)	None
2.5mm APC	≤50	5~12	(-50, +50)	8±0.2
1.25mm UPC	≤50	7~25	(-50, +50)	None
1.25mm APC	≤50	5~12	(-50, +50)	8±0.2

Product Images

Manufacturer Information

New Light Optics Technology Limited is a high-tech company specializing in optical communication products R&D, manufacturing, sales, and service. Established in 2011, we have over 6 years of OEM and manufacturing experience serving customers worldwide.

Our product line includes: Patch Cords/Pigtails, Patch Cord Cables, MTP/MPO Patch Cords, Fiber Optical Adapters, Attenuators, Fiber Optical Connectors, and more. Our products are widely used in telecommunications, fiber optical CATV, digital internet fiber transmission, data base stations, and other applications.

With advanced technology, professional R&D teams, sophisticated engineering skills, and high-quality control systems, our products are exported to over 60 countries including USA, Europe, Brazil, Middle East, and Asia, receiving high reputation and positive feedback from customers.

Contact & Support

WhatsApp: 008613534063703

Ordering & Delivery Information

Payment Methods: T/T, PayPal, Western Union, MoneyGram
Payment Terms: 30% deposit in advance, 70% balance paid before delivery
Packaging: International standard package (OPP bag + Carton Box)
Delivery Time: 2-7 working days (depending on quantity) after payment received
Warranty: 1 year after delivery
Shipping Methods: By air (DHL, TNT, UPS, FedEx) or by sea

Frequently Asked Questions

Q: Are you a manufacturer?

A: Yes, we are a manufacturer located in Shenzhen, China.

Q: What's your MOQ?

A: MOQ can be 1 piece, but we don't recommend ordering single units as the cost and price will be higher. Larger quantities receive more competitive pricing.

Q: What's the price?

A: Pricing depends on quantity. We provide our best pricing based on your order quantity, with competitive rates for larger volumes.

Q: Can you quote FOB price?

A: Yes, but due to the small size and weight of our products, most shipments are by air. We recommend providing detailed specifications and quantity for comprehensive pricing including freight. EXW or CFR pricing is often more suitable.

Q: How is your quality?

A: Our production follows IEC and European standards in near dust-free workshops using imported production and quality control equipment. All products are 100% tested before delivery.

Q: What's your lead time?

A: We operate three factories in China. For fiber optic patch cords, lead time is 2-3 working days for 5,000 pieces. Regular products are typically in stock, and we can accommodate urgent orders.

Q: What's your warranty?

A: For patch cords, we offer 2 years warranty from delivery date for non-artificial damage. For artificial damage, we provide free repair with customer responsible for freight costs.

Q: What's your packing?

A: We use international export packaging and can print your logo on the packaging upon request.
