LC Connector Single Mode Fiber Optic Pigtail 0.9mm with Low Insertion Loss

Brand Name:	New Light
Model Number:	LC / APC , LC / PC
MOQ:	1
Price:	0.2~10
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE , ISO , RoHS

Mode Type:

SM / MM

Cable Diameter:

0.6mm / 0.9mm

Cable Length:

Can Be Customized

Insertion Loss:

≤0.25dB

Return Loss:

APC≥65dB; PC≥55

Delivery Time:

2-7 Working Days

Payment Term:

30% Deposit In Advance , 70% Balance Paid Before Delivery

Supply Ability:

1000000

Highlight:

0.9mm Single Mode Fiber Optic Pigtail

0.9mm Fiber Optic Pigtail

0.9mm single mode fiber pigtails

Product Description

LC Connector Single Mode Fiber Optic Pigtail 0.9mm Low Insertion Loss

Fiber optic pigtails are fundamental components in fiber communication systems. These assemblies, composed of various connector types and optical cables, provide efficient field termination for communication devices. Manufactured and tested according to industrial standards, they meet stringent mechanical and performance specifications.

Product Features

High quality ferrule construction
Low insertion loss and high return loss
Excellent interchangeability and durability
Customizable to customer requirements
Compatible with Telcordia GR-326-core standards
Customizable lengths available
Multiple connector options: SC, FC, LC, ST, MU, E2000
Various cable types: G652D, G657A1, G657A2, G655, OM1, OM2, OM3, OM4
Tight buffer, semi-tight buffer, and loose buffer options

Product Specifications

Fiber Count	12	Fiber Mode	9/125μm
Connector Type	LC	Fiber Mode	SM
Breakout Length	1.5m	Jacket Material	PVC/LSZH
Insertion Loss	≤ 0.25dB	Interchangeability	≤0.2dB
Return Loss	≥ 50dB	Vibration	≤0.2dB
Operating Temperature	-40~75°C	Storage Temperature	-45~85°C

Geometric Specifications (3D Interferometer Tested)

Type	Vertex Offset (μm)	Curvature Radius (mm)	Fiber Height (nm)	Angle Offset (°)
2.5mm UPC	≤50	10~25	(-50, +50)	None
2.5mm APC	≤50	5~12	(-50, +50)	8±0.2
1.25mm UPC	≤50	7~25	(-50, +50)	None
1.25mm APC	≤50	5~12	(-50, +50)	8±0.2

Applications

Local area networks (LAN)
Wide area networks (WAN)
CATV and metro test equipment
Telecommunication networks
Data processing networks
Premise installations
Video and military active device termination

Product Illustration

Contact via WhatsApp: 008613534063703

Company Profile

New Light Optics Technology Limited is a high-tech company specializing in optical communication products R&D, manufacturing, sales, and service. Established in 2011, our factory has over 6 years of OEM and manufacturing experience serving customers worldwide.

Our product line includes: Patch Cords/Pigtails, Patch Cord Cables, MTP/MPO Patch Cords, Fiber Optical Adapters, Attenuators, Fiber Optical Connectors, and more. Our products are widely used in telecommunications, fiber optical CATV, digital internet fiber transmission, data base stations, and related applications.

With advanced technology, professional R&D teams, sophisticated production equipment, and stringent quality control systems, our products are exported to over 60 countries including USA, Europe, Brazil, Middle East, and Asia, receiving high customer satisfaction.

Payment Terms & Delivery

Payment Methods: T/T, PayPal, Western Union, MoneyGram
30% deposit in advance, 70% balance paid before delivery
Packaging: International standard (OPP bag + Carton Box)
Delivery Time: 2-7 working days (depending on quantity)
Warranty: 1 year after delivery
Shipping Methods: Air (DHL, TNT, UPS, FedEx) or Sea (upon request)

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer located in Shenzhen, China.

What is your minimum order quantity (MOQ)?

MOQ can be 1 piece, but larger quantities receive more competitive pricing.

How is your product quality?

Our production follows IEC and European standards in near dust-free workshops using imported equipment. All products are 100% tested before delivery.

What is your lead time?

Regular products are in stock. Custom orders: 2-3 working days for 5,000 pieces. We accommodate urgent orders.

Do you offer OEM/ODM services?

Yes, we provide OEM/ODM services and can sign confidentiality agreements.

Can I request samples?

Free samples available for adapters, attenuators, patch cords, and pigtails (customer pays shipping). Sample charges for high-value products are refundable with order placement.
