Single Mode Fiber Optic Pigtail with 12 Colors and 0.9mm SC/APC Connector

Brand Name:	New Light
Model Number:	SC / APC
MOQ:	1
Price:	0.2~10
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE , ISO , RoHS

Connector Type:

SC ( Can Be E2000, LC, FC, ST)

Mode Type:

Single Mode

Cable Color:

Usual 12 Colors

Cable Length:

Can Be Customized

Insertion Loss:

≤ 0.25dB

Return Loss:

APC≥65dB; PC≥55

Delivery Time:

2-7 Working Days

Payment Term:

30% Deposit In Advance , 70% Balance Paid Before Delivery

Supply Ability:

1000000

Highlight:

SC APC Fiber Optical Pigtail

0.9mm Fiber Optical Pigtail

Product Description

Single Mode Fiber Optical Pigtail 12 Colors 0.9mm SC/APC Connector

12 Colors 0.9mm SC/APC Connector Single Mode Fiber Optic Pigtail

Fiber Optic Pigtails Overview

Fiber optic pigtails provide efficient field termination for communication devices. Manufactured and tested according to industrial standards, these pigtails meet stringent mechanical and performance specifications. Designed for splice applications when terminating outside plant cable, each unit consists of 12 simplex pigtails in different colors. Complies with Telcordia GR-326 Core and ROHS requirements.

WHATSAPP 008613534063703

Applications

Local area networks (LAN)
Wide area networks (WAN)
CATV and metro test equipment
Telecommunication networks
Data processing networks
Premise installations
Video and military active device termination

Features

Available connector types: SC, FC, LC, ST, MU, E2000
Compatible cable types: G652D, G657A1, G657A2, G655, OM1, OM2, OM3, OM4
Cable sizes: 0.6mm or 0.9mm
12 color options for easy identification
Both 250um and 900um available in matching colors
Tight buffer, semi-tight buffer, and loose buffer options

Product Specifications

Fiber Count	12	Fiber Mode	9/125μm
Connector Type 1	SC/APC	Connector Type 2	Unterminated
Fiber Mode	SM	Breakout Length	1.5m
Wavelength	1310/1550nm	Jacket Material	PVC/LSZH
Insertion Loss	≤ 0.25dB	Interchangeability	≤0.2dB
Return Loss	≥ 50dB	Vibration	≤0.2dB
Operating Temperature	-40~75°C	Storage Temperature	-45~85°C

Geometric Specifications (3D Interferometer Tested)

Type	Vertex Offset (μm)	Curvature Radius (mm)	Fiber Height (nm)	Angle Offset (°)
2.5mm UPC	≤50	10~25	(-50, +50)	None
2.5mm APC	≤50	5~12	(-50, +50)	8±0.2
1.25mm UPC	≤50	7~25	(-50, +50)	None
1.25mm APC	≤50	5~12	(-50, +50)	8±0.2

Product Diagram

Company Introduction

New Light Optics Technology Limited is a high-tech company specializing in optical communication products R&D, manufacturing, sales, and service. Established in 2011, our factory has over 6 years of OEM and manufacturing experience serving customers worldwide.

Our product line includes: Patch Cords/Pigtails, Patch Cord Cables, MTP/MPO Patch Cords, Fiber Optical Adapters, Attenuators, Fiber Optical Connectors, and more. Our products are widely used in telecommunications, fiber optical CATV, digital internet fiber transmission, data base stations, and related applications.

We feature advanced technology, professional R&D teams, sophisticated production equipment, and experienced engineers. With a high-quality control system, our products are exported to over 60 countries including USA, Europe, Brazil, Middle East, and Asia, receiving high reputation and positive customer feedback.

Payment Terms & Delivery

Payment Methods: T/T, PayPal, Western Union, MoneyGram
Payment Terms: 30% deposit in advance, 70% balance paid before delivery
Packaging: International standard package (OPP bag + Carton Box)
Delivery Time: 2-7 working days (depending on quantity) after payment received
Warranty: 1 year after delivery
Shipping Methods: By air (DHL, TNT, UPS, FedEx) or by sea (upon request)

Packaging

Products are packaged in OPP bags with carton boxes for external protection to prevent damage during delivery.

Frequently Asked Questions

Q: Are you a manufacturer?

A: Yes, we are a manufacturer located in Shenzhen, China.

Q: What's your MOQ?

A: MOQ can be 1 piece, but we don't recommend ordering single pieces due to higher costs and pricing.

Q: What's the price?

A: Pricing depends on quantity. We provide competitive pricing for larger quantities upon request.

Q: Can you quote FOB price?

A: Yes, but due to small size and weight, most shipments are by air. We recommend providing detailed specifications and quantity for comprehensive pricing including freight. EXW or CFR pricing is often more suitable.

Q: How is your quality?

A: Our production follows IEC and European standards in near dust-free workshops. We use imported production and quality control equipment, with 100% product testing before delivery.

Q: What's your lead time?

A: We operate three factories in China. For fiber optic patch cords, lead time is 2-3 working days for 5,000 pieces. Regular products are available from stock, and we accommodate urgent orders.

Q: What's your warranty?

A: For patch cords, we offer 2 years warranty for non-artificial damage. Artificial damage repairs are free, but freight costs are the customer's responsibility.

Q: What's your packing?

A: We use international export packaging and can print your logo on packaging upon request.
