MPO MTP Patch Cord

Low Insertion Loss OM3 SM MPO Breakout Cable with Custom Length and 12 Colors for MTP Patch Panel

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

Low Insertion Loss OM3 SM MPO Breakout Cable with Custom Length and 12 Colors for MTP Patch Panel

Brand Name:	NEW LIGHT
Model Number:	MPO
MOQ:	100pcs
Price:	0.1~100
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

ShenZhen , China

Certification:

CE , ISO , RoHS

Connector Type:

Mpo

Mode Type:

MM/SM

Cable Color:

12 Colors

Cable Diameter:

0.9mm

Cable Length:

Can Be Customized

Insertion Loss:

≤0.35db

Return Loss:

APC≥65dB; PC≥55

Supply Ability:

12000 pcs / day

Highlight:

OM3 SM MPO Breakout Cable

PVC LSZH MPO Breakout Cable

Data communication MPO MTP Patch Cord

Product Description

OM3 SM MPO Breakout Cable PVC/LSZH Jacket for MTP Patch Panel

Low insertion loss OM3 PVC 3.0mm OM4 (50/125) MPO cable designed specifically for MTP patch panel applications.

Product Overview

Fiber optic patch cords are terminated at both ends with connectors for rapid connection to CATV systems, optical switches, transmitters, receivers, terminal boxes, and other telecommunications equipment. These cables feature low insertion loss and high return loss characteristics.

Our extensive range includes simplex or duplex fiber patch cables terminated with state-of-the-art connectors available in various combinations including ST, SC, LC, FC, and MPO/MTP with PC, UPC, or APC polish types.

MPO breakout cables provide a cost-effective alternative to time-consuming field termination, designed for high-density fiber patching in data centers where space optimization and simplified cable management are essential. Optimized for 40G QSFP+ SR4 to 10G SFP+ SR, 100G QSFP SR4 to 25G SFP-25G-SR-S optics direct connection and high-density data center applications.

Our MTP/MPO high-density series ODF utilizes high-density fiber connectors with single/ribbon fibers factory-terminated and tested. Supports immediate onsite equipment connection and rapid data center deployment. The enclosure design facilitates easy connection to LC adapters using multi-fiber optical patch cords (sold separately) and slides into standard 19-inch racks or cabinet frames. Cassette modules are available as optional accessories.

Key Features

Flat surface alignment with distribution frame after cross screw installation prevents friction
Standard unit structure size compatible with various cabinet and rack installations
Multiple optical cable entry points with enlarged inlets for easy cable routing
Secure cable fixation using optical cable fixing columns or metal reinforcements

Applications

Data Center Infrastructure
Storage Area Network
Fiber Channel
Emerging 40 and 100Gbps protocols compatibility

Product Specifications

Fiber Count	12	Fiber Mode	9/125μm
Connector Type 1	LC	Connector Type 2	Unterminated
Fiber Mode	SM	Breakout Length	1.5m
Wavelength	1310/1550nm	Jacket Material	PVC/LSZH
Insertion Loss	≤ 0.25dB	Interchangeability	≤0.2dB
Return Loss	≥ 50dB	Vibration	≤0.2dB
Operating Temperature	-40~75°C	Storage Temperature	-45~85°C

Geometric Specifications (3D Interferometer Tested)

Type	Vertex Offset (μm)	Curvature Radius (mm)	Fiber Height (nm)	Angle Offset (°)
2.5mm UPC	≤50	10~25	(-50, +50)	None
2.5mm APC	≤50	5~12	(-50, +50)	8±0.2
1.25mm UPC	≤50	7~25	(-50, +50)	None
1.25mm APC	≤50	5~12	(-50, +50)	8±0.2

Product Diagrams

Packaging

Products are securely packaged using OPP bags inside carton boxes to ensure protection during delivery and transportation.

WhatsApp: +8613534063703

Frequently Asked Questions

Q: Are you a manufacturer?

A: Yes, we are a manufacturer located in Shenzhen, China.

Q: What's your MOQ?

A: MOQ can be 1 piece, but we recommend larger quantities for better pricing as single-unit orders incur higher costs.

Q: What's the price?

A: Pricing varies by quantity. We provide competitive pricing for bulk orders upon request.

Q: Can you quote FOB price?

A: We primarily ship via air couriers (DHL, TNT, UPS, FEDEX). EXW or CFR pricing is typically more suitable. For large sea shipments, we can provide freight quotes.

Q: How is your quality?

A: We manufacture according to IEC and European standards in near dust-free environments using imported production and quality control equipment. All products undergo 100% testing before delivery.

Q: What's your lead time?

A: With three factories in China, we can typically produce 5,000 patch cords within 2-3 working days. Regular products are available from stock for urgent requirements.

Q: What's your warranty?

A: Patch cords carry a 2-year warranty against non-artificial damage. Artificial damage repairs are free, but shipping costs are the customer's responsibility.

Q: What's your packing?

A: We use international export packaging and can customize with your logo upon request.

Q: Can you do OEM/ODM?

A: Yes, we accept OEM/ODM orders and can sign confidentiality agreements.

Q: Can I have a sample?

A: Free samples available for adapters, attenuators, patch cords, and pigtails (customer pays shipping). Higher-value products require sample charges refundable with orders.

Q: How can I order?

A: Contact us with product specifications and quantity. We'll provide pricing and lead time. Orders proceed with proforma invoice and payment confirmation.

Q: What are your payment terms?

A: We accept T/T, Western Union, PayPal, and MoneyGram. For large orders: 50% deposit, 50% balance before delivery.
