PVC / LSZH MPO MTP Trunk Cable Elite Polarity B Key Up - Key Up For Data Center

PVC / LSZH MPO MTP Trunk Cable Elite Polarity B Key Up - Key Up For Data Center
PVC / LSZH MPO MTP Trunk Cable Elite Polarity B Key Up - Key Up For Data Center
PVC / LSZH MPO MTP Trunk Cable Elite Polarity B Key Up - Key Up For Data Center PVC / LSZH MPO MTP Trunk Cable Elite Polarity B Key Up - Key Up For Data Center PVC / LSZH MPO MTP Trunk Cable Elite Polarity B Key Up - Key Up For Data Center PVC / LSZH MPO MTP Trunk Cable Elite Polarity B Key Up - Key Up For Data Center

Large Image :  PVC / LSZH MPO MTP Trunk Cable Elite Polarity B Key Up - Key Up For Data Center

Product Details:
Place of Origin: ShenZhen , China
Brand Name: NEW LIGHT
Certification: CE , ISO , RoHS
Model Number: MPO
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: can be negotiated
Packaging Details: OPP bag + carton box
Delivery Time: 5-7 working days after receive payment
Payment Terms: T/T, Western Union, MoneyGram , paypal
Supply Ability: 12000 pcs / day

PVC / LSZH MPO MTP Trunk Cable Elite Polarity B Key Up - Key Up For Data Center

Description
Connector Type: Mtp Mode Type: MM/SM
Cable Color: 8/12 Cable Diameter: 3.0mm 0.9mm
Cable Length: 15m/5m/10m Insertion Loss: ≤0.35db
Return Loss: APC≥65dB; PC≥55
High Light:

Data Center MPO MTP Trunk Cable

,

Polarity B MPO MTP Trunk Cable

,

PVC LSZH MPO MTP Trunk Cable

Low insertion loss 3.0mm Elite polarity B Key up-key up trunk Cable for Data Center



Overview of Elite MTP/MPO -LC Fan out



MTP/MPO cables have multi-core connectors that provide more consistent and reliable performance when used in high-density, low-loss cabling, thus becoming an integral part of 40G/100G data transmission in large data centers. Hence, TIA standards define three types of polarized MTP cables: Type A, Type B, and Type C. Different types of MTP polarity cables may have different applications. In this tutorial, we will mainly introduce type-B polarity MTP cables and their applications. For a complete polarity guide of FS MTP cables, you can refer to the white paper Understanding Fiber Polarity.



MTP/MPO Type-B Cable Overview
The type-B polarity MTP cable meaning is to use a key-up connector on both ends of the cable. Often referred to as a 40G MTP cable, the type-B MTP cable is extremely versatile. This cable assembly can be used to plug directly between your 40G QSFP+ optic transceivers. As you can see in the diagram, this cable has a "flipped" polarity and will result in a Pin 1 to Pin 12 relationship. This is extremely useful because 40G optics utilize parallel optics, meaning instead of alternating Tx and Rx in a duplex pattern, the port will look like the following diagram.





MTP/MPO Type-B Cable Categories
Based on its different functions, MTP type-B cable can be divided into two main categories: MTP Trunk cables and MTP-LC breakout cables. Depending on the nature of the socket MTP trunk cables are further divided into female-female, female-male, and male-male. When connecting two 40G SR4 QSFP+ transceivers in parallel optics, only female-female type B MTP cables should be used. For MTP-LC breakout cables, female MTP-LC breakout cables and male MTP-LC breakout cables are available.
Note: MTP connectors can be divided into female connector and male connector. Female connector does not have guide pins, while male connector has two guide pins. The connections between the connectors are precisely aligned with the pin, and the two MTP connectors connected to each other must be male and female.







Products info

Fiber count 12 Fiber Mode 9/125μm
Connector Type1 LC Connector Type2 Unterminated
Fiber Mode SM Breakout length 1.5m
Wavelength 1310/1550nm Jacket Material PVC/LSZH
Insertion loss ≤0.25dB Interchangeability ≤0.2dB
Return loss ≥50dB Vibration ≤0.2dB
Operating temperature -40~75°C Storage temperature -45~85°C







Geometric Specification (only for 3D interferometer tested)

Type Vertex offset(um) Curvature radius(mm) Feber Height(nm) Angle offset(°)
2.5mm UPC ≤50 10~25 (-50, +50) None
2.5mm APC ≤50 5~12 (-50, +50) 8±0.2
1.25mm UPC ≤50 7~25 (-50, +50) None
1.25mm APC ≤50 5~12 (-50, +50) 8±0.2



PVC / LSZH MPO MTP Trunk Cable Elite Polarity B Key Up - Key Up For Data Center 0





PVC / LSZH MPO MTP Trunk Cable Elite Polarity B Key Up - Key Up For Data Center 1









Pakcing



We will pack it by OPP bag and carton box outside . in order to protect the goods are not damaged when delivery .







FQA



1. Q : Are you manufacturer ?

A: yes, we are manufacturer in Shenzhen,China



2. Q : What's your MOQ ?

A: MOQ can be 1 pcs , but we are not suggest to order 1 pcs , because the cost will be higher , so that the price will be higher than your budget .



3. Q : What's the price ?

A : The price is according to your quantity . After you let us know your quantity , we will offer our best price for you . Big Quantity will get very competitive price .



4. Q: Can you quote FOB price ?

A : yes we can , But due to the size and weight is not big , most are delivery by air ,DHL , TNT , UPC , FEDEX ,etc . So it it difficult to do FOB price . The best way is let us know your detailed specifications and quantity , we will offer the freight with products price for your reference .



We have very competitive price logist . If your quantity is big and there are dozens of carton boxes , we can figure out freight by sea for your reference .



EXW price or CFR price will be better . You can contact us for more solution if you need .



5. Q: How is your quality ?

A: Our production is according to IEC , Europe standard production , almost closed to dust-free workshop . Imported production equipment and quality control equipment . Especially MTP Daisi equipments .



All the products are 100% test before delivery .



6. Q : Whats your lead time ?

A : We have three factories in China . One factory for fiber optic cable production , two factories for patch cord , PLC , ODF , adaptor ,attenuators ,etc .

For fiber optic patch cord , the lead time can be 2 -3 owrking days for 5000 pcs . regular products we are have it in stock . We can deal with urgent order for you . More informations , you can feel free to contact us .



7. Q : Whats your warranty ?

A : for patch cord , we have 2 years warranty since delivery , but only responsible for non-artificial damage . For artificial damage , we can repare it for you for free ,but freight will be paid by your side .



8. Q : Whats your packing ?

A : We are using international export package . attached some packing of different products for your reference . We also can print your logo on the packing



9. Q: Can you do OEM/ODM ?

A: yes , we can . We are manufacturer , all products are accept OEM /ODM . we can sign the Confidentiality agreement .



10. Q: Can I have a sample ?

A: It depends on which products , for adaptor , attenuator ,patch cord , pigtail , we can provide a sammple for you for free . But freight repaid by your side .

For big value products , we can't offer it for free , sample charge and freight repaid first , after you placed order , the sample charge will be returned.



11. Q: How can I order ?

A: 1. send mail to us or send inquiry . let us know the products name , detailed specifications , quantity . Provide your receive address if you need us to figure out freight for you .

2. After we know your requirements , will offer our best price for you ,with lead time . The price is according to your quantity .

3. When you accept the quotation , we will make Profoma Invoice with our bank account .

4. We will arrange the production for you after we received payment .

5. Before we delivery will confirm the receive information with you again .and will send the tracking number to you after delivery .

6. We will try our best to meet your requirements for long-term cooperation .



12. Q: What your payment term ?

A: T/T , Western Union , Paypal ,MoneyGram at once .For big amount , can 50% deposit in advance , 50% balance paid before delivery .



Contact Details
NEW LIGHT OPTICS TECHNOLOGY LIMITED

Contact Person: Alice

Tel: 0086-13534063703

Fax: 00-86-85242074

Send your inquiry directly to us (0 / 3000)
