Parameter	Specification	Parameter	Specification
Fiber Count	12	Fiber Mode	9/125μm SM
Connector Type 1	LC	Connector Type 2	Unterminated
Breakout Length	1.5m	Jacket Material	PVC/LSZH
Wavelength	1310/1550nm	Interchangeability	≤0.2dB
Insertion Loss	≤ 0.25dB	Vibration	≤0.2dB
Return Loss	≥ 50dB	Operating Temperature	-40~75°C
Storage Temperature	-45~85°C

Geometric Specifications

(3D Interferometer Tested)

Type	Vertex Offset (μm)	Curvature Radius (mm)	Fiber Height (nm)	Angle Offset (°)
2.5mm UPC	≤50	10~25	(-50, +50)	None
2.5mm APC	≤50	5~12	(-50, +50)	8±0.2
1.25mm UPC	≤50	7~25	(-50, +50)	None
1.25mm APC	≤50	5~12	(-50, +50)	8±0.2

Packaging

Products are securely packaged in OPP bags and carton boxes to ensure protection during delivery and transportation.

Contact: WHATSAPP +8613534063703

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer located in Shenzhen, China.

What is your MOQ?

MOQ can be 1 piece, but we recommend larger quantities for better pricing.

What is the price?

Pricing depends on quantity. We offer competitive pricing for bulk orders.

Can you quote FOB price?

We typically recommend EXW or CFR pricing for optimal freight solutions.

How is your quality?

We follow IEC and European standards with imported production equipment and 100% testing before delivery.

What is your lead time?

2-3 working days for 5000 pieces, with regular products available from stock.

What is your warranty?

2-year warranty for patch cords, covering non-artificial damage.

Can you do OEM/ODM?

Yes, we accept OEM/ODM orders and can sign confidentiality agreements.

Can I have a sample?

Free samples available for certain products with freight prepaid by customer.

Tags:

ftth fiber optic cable

fiber optic pigtail

Low Insertion Loss MPO MTP Cassette

Products Details

Home > Products >

MPO MTP Patch Cord

Low Insertion Loss ≤0.35dB 3.0mm MPO to LC Cassette 12/24 Fiber MPO/MTP Cassette

All Category

Optical Fiber Patch Cord

MPO MTP Patch Cord

MPO MTP Cable

MPO Cassette Module

Fiber Optic Patch Panel

Fiber Optic Pigtail

FTTH Termination Box

Fiber Optic Connectors

Quick Assembly Connector

Fiber Optic Adapter

Fiber Optic Attenuator

Fiber Optic Loopback

Fiber Optic Cables

Fiber Optic Tools

Fiber Optic Transceiver

Fiber Optic Splitter

Fiber Optic WDM

Fiber Optic Splice Closure

Copper Patch Cords

Rj45 Patch Panel

RJ45 Ethernet Connector

Drone Fiber Optic

Switch And Socket

Low Insertion Loss ≤0.35dB 3.0mm MPO to LC Cassette 12/24 Fiber MPO/MTP Cassette

Brand Name:	NEW LIGHT
Model Number:	MPO
MOQ:	100pcs
Price:	0.1~100
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

ShenZhen , China

Brand Name:

NEW LIGHT

Certification:

CE , ISO , RoHS

Model Number:

MPO

Connector Type:

Mtp

Mode Type:

MM/SM

Cable Color:

8/12

Cable Diameter:

3.0mm 0.9mm

Cable Length:

15m/5m/10m

Insertion Loss:

≤0.35db

Return Loss:

APC≥65dB; PC≥55

Minimum Order Quantity:

100pcs

Price:

0.1~100

Packaging Details:

OPP bag + carton box

Delivery Time:

5-7 working days after receive payment

Payment Terms:

T/T,Western Union,MoneyGram,paypal

Supply Ability:

12000 pcs / day

Highlight:

Low Insertion Loss MPO MTP Cassette

3.0mm MPO to LC Cassette

PVC LSZH MPO MTP Cassette

Product Description

Low Insertion Loss 3.0mm MPO to LC Cassette

12/24 Fiber MPO/MTP Cassette with superior performance characteristics for high-density fiber optic applications.

Product Overview

MPO to LC Cassette provides efficient connectivity between high-density MPO/MTP backbone cables and LC duplex equipment ports.

Polarization Methods Compatibility

Designed to support all three TIA 568 standard polarization methods (A, B, and C) using corresponding MTP fiber types:

Type A (Straight Cable): Key-up to key-down configuration with identical fiber positions at both ends

Type B: Reverses fiber positions (1 to 12, 12 to 1) with key-up orientation at both ends

Type C: Pair-wise fiber reversal for specific connectivity requirements

MPO/MPO Polarity Management

Proper polarity maintenance is critical for signal transmission integrity. Our cassettes ensure correct pin alignment and connectivity methods.

Technical Specifications

Parameter	Specification	Parameter	Specification
Fiber Count	12	Fiber Mode	9/125μm SM
Connector Type 1	LC	Connector Type 2	Unterminated
Breakout Length	1.5m	Jacket Material	PVC/LSZH
Wavelength	1310/1550nm	Interchangeability	≤0.2dB
Insertion Loss	≤ 0.25dB	Vibration	≤0.2dB
Return Loss	≥ 50dB	Operating Temperature	-40~75°C
Storage Temperature	-45~85°C
