Product Details:
|
| Name: | MPO MTP Cable | Material: | LSZH, OFNP Or OFNR |
|---|---|---|---|
| Mode Type: | OM4 | Core Type: | 12 Core |
| Connector: | MPO,MTP | Color: | Aqua,orange,yellow,Yellow/ Red/ Aqua |
| High Light: | 24 Core MPO MTP Cable,OM4 MPO MTP Cable,Duplex LC MPO Breakout Cable |
||
12 and 24 core cable fiber types MPO to 4 duplex LC breakout cable
Quick Detail:
1 . Cable type: 3.2 mm round LSZH jacketed cable
2 . Bandwidth fiber: Multimode OM3 XG lazer optimized ≥2000MHzxKm @850nm
3 . Single Mode OS2 ITU-T G.652d 9micron
4 . Connector-Type: High connectivity MPO
5 . Connector Interface: MPO interface requirements: IEC61754-4.20 and IEC61754-7
6 . Connector End face: MPO end face geometry requirements: EN50377-15-1
7 . Polishing Quality: Polished end-face quality: IEC61300-3-35
8 . Insertion Loss: ≤ 0.5dB OM3 / ≤ 0.6dB SM OS2
9 . Return Loss: ≥ 25dB OM3; ≥ 35dB
Description
MTP/MPO cables play an important role in ultra-high-density cabling. They deliver the extra bandwidth needed for high data transmission applications, and also have the advantages of shorter installation times, tested and guaranteed quality, and greater reliability. Combining to meet the 40GBASE-SR4 and 100GBASE-SR10 standard, the MTP/MPO multi-fiber connector of MTP/MPO cables is about the same size as a SC connector but can accommodate 8, 12, or 24 fibers, thus offering savings in circuit card and rack space.
Features
1 . MPO / MTP connector interface patch cord
2 . Customizable fiber optic cable length
3 . Available in 12 and 24 core cable fiber types
4 . Uses multi-mode 50/125um, OM3 /OM4 Bend-insensitive fiber or single-mode (G652D, G657A1) Bend-insensitive fiber types with type 2mm diameter
5 . Comply with IEC 61754-7, Telcordia GR-1435-CORE
6 . RoHS 6 compliant(lead free)
7 . Supports applications such as 40G LAN, 100G LAN or OTU4 100Gbps flipped pairs (pin 1 to pin 2) and method A (key-up to key-down) MPO connectors. It does not offer a migration pathway to 40-/100-GbE.
Standard Compliance
• EIA/TIA-455-21A
• TIA 604-5 (FOCIS 5)
• Telcordia GR-326-CORE
• IEC61754-7
Applications
• Data Centre Infrastructure
• Storage Area Network – Fiber Channel
• Parallel Optics
• 10Gbps, 25Gbps and emerging 40Gbps, 100Gbps Protocol
MPO MTP Cable Technical Parameter
| Item | Technical Parameters | |
| Connector | MPO/MTP(F or M) | MPO/MTP (F or M) |
| Operation Temperature | -40°C ~ +80°C | |
| Storage Temperature | -40°C ~ +85°C | |
| Insertion Loss |
SM: ≤ 0.75dB (standard value), ≤0.35dB (typical value); MM:≤ 0.50dB (standard value), ≤0.35dB (typical value); |
|
| Return Loss | SM:≥60dB; MM:≥35dB | |
| The MPO end type | Male: with guide pin; Female: without guide pin | |
| Fiber count | 8,12&24 fiber | |
| Connector type of the other end | MPO-female , MPO-male , FC , SC , ST , MU , LC , E2000 | |
| Fiber mode | Single-mode (G652,G655,G657), multi-mode (50, 62.5, OM2, OM3, OM4) | |
| Fiber cable type | 250um ribbon fiber,ribbon cable,Bundle fiber optic cable | |
The three polarity methods Type A, Type B and Type C are used to guarantee the right bi-directional allocation.
Pakcing
We will pack it by OPP bag and carton box outside . in order to protect the goods are not damaged when delivery .
FQA
1. Q : Are you manufacturer ?
A: yes, we are manufacturer in Shenzhen,China
2. Q : What's your MOQ ?
A: MOQ can be 1 pcs , but we are not suggest to order 1 pcs , because the cost will be higher , so that the price will be higher than your budget .
3. Q : What's the price ?
A : The price is according to your quantity . After you let us know your quantity , we will offer our best price for you . Big Quantity will get very competitive price .
4. Q: Can you quote FOB price ?
A : yes we can , But due to the size and weight is not big , most are delivery by air ,DHL , TNT , UPC , FEDEX ,etc . So it it difficult to do FOB price . The best way is let us know your detailed specifications and quantity , we will offer the freight with products price for your reference .
We have very competitive price logist . If your quantity is big and there are dozens of carton boxes , we can figure out freight by sea for your reference .
EXW price or CFR price will be better . You can contact us for more solution if you need .
5. Q: How is your quality ?
A: Our production is according to IEC , Europe standard production , almost closed to dust-free workshop . Imported production equipment and quality control equipment . Especially MTP Daisi equipments .
All the products are 100% test before delivery .
6. Q : Whats your lead time ?
A : We have three factories in China . One factory for fiber optic cable production , two factories for patch cord , PLC , ODF , adaptor ,attenuators ,etc .
For fiber optic patch cord , the lead time can be 2 -3 owrking days for 5000 pcs . regular products we are have it in stock . We can deal with urgent order for you . More informations , you can feel free to contact us .
7. Q : Whats your warranty ?
A : for patch cord , we have 2 years warranty since delivery , but only responsible for non-artificial damage . For artificial damage , we can repare it for you for free ,but freight will be paid by your side .
8. Q : Whats your packing ?
A : We are using international export package . attached some packing of different products for your reference . We also can print your logo on the packing
9. Q: Can you do OEM/ODM ?
A: yes , we can . We are manufacturer , all products are accept OEM /ODM . we can sign the Confidentiality agreement .
10. Q: Can I have a sample ?
A: It depends on which products , for adaptor , attenuator ,patch cord , pigtail , we can provide a sammple for you for free . But freight repaid by your side .
For big value products , we can't offer it for free , sample charge and freight repaid first , after you placed order , the sample charge will be returned.
