12 Fibers 40G MPO MTP Cable OM3 OM4 Multimode Strands Polarity A Plenum

Brand Name:	New Light
Model Number:	MPO / MTP - MPO / MTP
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Name:

MPO MTP Cable

Material:

LSZH, OFNP Or OFNR

Mode Type:

OM3 OM4 OS2

Core Type:

12 /24core

Connector:

MTP/MPO

Color:

Aqua,orange,yellow,Yellow/ Red/ Aqua

Supply Ability:

500 pcs per day

Highlight:

OM3 40G MPO Cable

Polarity A Plenum OM4 MPO Cable

12 Fibers 40G OM3 MPO Cable

Product Description

12 Fibers 40G MPO Cable OM3 OM4 Multimode Strands Polarity A Plenum

Product Overview

The NEW LIGHT OPTICS OM4 Fiber Cable is designed for high-speed fiber optic networking applications in buildings, data centers, and telecommunications. This plenum-rated cable is specifically engineered for vertical pathways, shafts, and spaces between building floors, making it ideal for schools, healthcare facilities, and government buildings.

Key Features

Factory-terminated for consistent quality, high performance, and reduced installation time
100% tested for low insertion loss performance and high return loss
MPO Female to 4 x LC duplex harness cable configuration
OM4 (OM3) 50/125μm Fiber construction
Type B polarity for 40G QSFP eSR4 and 10GBASE-SR optics interconnect
Optimized performance with elite MTP and discrete premium connector options
Compliant with IEC 61754-7, TIA/EIA 604-5, Telcordia GR-1435-CORE and RoHS
LSZH Jacket by default for enhanced safety

Technical Specifications

Parameter	Specification
Connector	MPO/MTP (Female or Male)
Operation Temperature	-40°C to +80°C
Storage Temperature	-40°C to +85°C
Insertion Loss	SM: ≤ 0.75dB (standard), ≤0.35dB (typical); MM: ≤ 0.50dB (standard), ≤0.35dB (typical)
Return Loss	SM: ≥60dB; MM: ≥35dB
MPO End Type	Male: with guide pin; Female: without guide pin
Fiber Count	8, 12 & 24 fiber options
Fiber Mode	Single-mode (G652,G655,G657), multi-mode (50, 62.5, OM2, OM3, OM4)

MPO Cable Applications

MPO fiber patch cables are compliant with IEC-61754-7 and TIA-604-5 standards, supporting high-density applications that require superior performance and rapid installation. These cables enable easy migration from 10GbE to 40GbE or 100GbE networks.

Polarity Configuration

The three polarity methods (Type A, Type B, and Type C) ensure proper bi-directional signal allocation for reliable data transmission.

Packaging

Products are securely packaged in OPP bags and carton boxes to ensure protection during delivery and transportation.

Contact Information

WhatsApp: +8613534063703

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer based in Shenzhen, China.

What is your minimum order quantity (MOQ)?

MOQ can be 1 piece, but we recommend larger quantities for better pricing.

What is your quality assurance process?

We follow IEC and European standards with imported production equipment. All products undergo 100% testing before delivery.

What is your lead time?

We maintain three factories in China with lead times of 2-3 working days for 5000 pieces of fiber optic patch cords. Regular products are typically in stock.

What is your warranty policy?

We offer a 2-year warranty for patch cords covering non-artificial damage since delivery.

Do you offer OEM/ODM services?

Yes, we accept OEM/ODM orders and can sign confidentiality agreements.
