LSZH Jacket OM4 Multimode MPO MTP Cable with 12/24 Core for High-Speed Networking

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

86 13534063703

Contact Now

LSZH Jacket OM4 Multimode MPO MTP Cable with 12/24 Core for High-Speed Networking

Brand Name:	New Light
Model Number:	MPO / MTP - MPO / MTP
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Name:

MPO MTP Cable

Material:

LSZH, OFNP Or OFNR

Mode Type:

OM3 OM4 OS2

Core Type:

12 /24core

Connector:

MTP/MPO

Color:

Aqua,orange,yellow,Yellow/ Red/ Aqua

Supply Ability:

500 pcs per day

Highlight:

LSZH MPO MTP Cable

OFNP MPO MTP Cable

OFNR OM4 Fiber Cable

Product Description

LSZH OFNP OFNR MPO MTP Cable Multimode Strands OM4 Fiber Cable

12/24 Fibers OM3 Multimode Strands Polarity A Plenum OM4 Fiber Cable

The NEW LIGHT OPTICS OM4 Fiber Cable is designed for high-speed fiber optic networking applications in buildings, data centers, and telecommunications infrastructure. This multimode cable is ideal for vertical pathways, shafts, and inter-floor spaces. The LC fiber jumper delivers reliable performance in demanding, high-density cable environments, making it suitable for schools, healthcare facilities, and government buildings.

Plenum MTP®/MPO Fiber Optic Cables

These high-speed multimode 50/125μm OM4 Polarity Type fiber cables feature MTP® fiber optic connectors on both ends (MTP-MTP). The MTP® ("Multifiber Termination Push-on") connector, developed by USConec, accommodates up to twelve optical fibers within a single ferrule.

Each MTP® cable contains 12 fiber channels in a connector smaller than most duplex connections available today. MTP fiber cables represent a high-performance version of MPO-style cables and are fully compatible with MPO connectors.

Available Polarity Types

Type-A (Straight Through)
Type-B (Cross, Flipped)
Type-C (Cross Pair, Rollover)

Features of OM4 Fiber Cable

Factory-terminated for consistent quality, high performance, and reduced installation time
100% tested for low insertion loss performance and high return loss
MPO Female to 4 x LC duplex harness cable configuration
Suitable for MPO applications
OM4 (OM3) 50/125μm Fiber construction
Type B polarity, optimized for 40G QSFP eSR4 and 10GBASE-SR optics interconnect
Optimized performance with elite MTP and discrete premium connector options available
Compliant with IEC 61754-7, TIA/EIA 604-5, Telcordia GR-1435-CORE and RoHS standards
LSZH Jacket by default

MPO fiber patch cable complies with IEC-61754-7 and TIA-604-5 (FOCIS-5) standards, making it suitable for various applications.

MPO MTP Cable Overview

New Light factory produces MTP/MPO harness cables and MTP/MPO trunk cables, which differ in function and application requirements.

Polarity Selection Guide

Type A - Straight: Straight-through polarity for connecting patch panels. Wired in mirrored configuration from Pin 1 to Pin 1, etc.

Type B - Rollover: Primarily for connecting to switches and transceivers in 40Gb applications. Wired from Pin 1 to Pin 12, then 2 to 11, and so forth.

Type C - Flipped: Pair-Flipped polarity, most commonly used for cassette-to-cassette applications. Pin 1 to Pin 2, 2 to 1, 3 to 4, 4 to 3, etc. This is the default polarity option.

MPO MTP Cable Features

US Conec MTP connector, Senko MPO Plus premium connector
OS2, OM3, OM4 fiber grades (OM1 and OM2 available)
0.35dB Elite low loss MTP/MPO connector as well as standard versions of 0.6/0.75dB
Factory terminated and tested
Easy migration from 10GbE to 40GbE or 100GbE
Pulling eyes available as an option to protect fiber ends during installation

MPO MTP Cable Technical Parameters

Item	Technical Parameters
Connector	MPO/MTP(F or M)
Operation Temperature	-40°C ~ +80°C
Storage Temperature	-40°C ~ +85°C
Insertion Loss	SM: ≤ 0.75dB (standard), ≤0.35dB (typical); MM:≤ 0.50dB (standard), ≤0.35dB (typical)
Return Loss	SM:≥60dB; MM:≥35dB
MPO End Type	Male: with guide pin; Female: without guide pin
Fiber Count	8, 12 & 24 fiber
Connector Type of Other End	MPO-female, MPO-male, FC, SC, ST, MU, LC, E2000
Fiber Mode	Single-mode (G652,G655,G657), multi-mode (50, 62.5, OM2, OM3, OM4)
Fiber Cable Type	250um ribbon fiber, ribbon cable, Bundle fiber optic cable

Contact: WhatsApp +8613534063703

The three polarity methods (Type A, Type B and Type C) ensure proper bi-directional signal allocation.

Packaging

Products are packaged in OPP bags with carton boxes for external protection, ensuring safe delivery and protection from damage during transportation.

Frequently Asked Questions

Q: Are you a manufacturer?

A: Yes, we are a manufacturer located in Shenzhen, China.

Q: What's your MOQ?

A: MOQ is 1 piece, but we recommend larger quantities for better pricing as single-piece orders incur higher costs.

Q: What's the price?

A: Pricing depends on quantity. We provide competitive pricing for larger orders upon request.

Q: Can you quote FOB price?

A: Yes, but due to small size and weight, most shipments are via air couriers (DHL, TNT, UPS, FEDEX). EXW or CFR pricing is typically more suitable. We provide freight quotes with product pricing upon request.

Q: How is your quality?

A: We manufacture according to IEC and European standards in near dust-free workshops using imported production and quality control equipment. All products undergo 100% testing before delivery.

Q: What's your lead time?

A: We operate three factories in China. For fiber optic patch cords, lead time is 2-3 working days for 5,000 pieces. Regular products are typically in stock, and we accommodate urgent orders.

Q: What's your warranty?

A: Patch cords carry a 2-year warranty from delivery date for non-artificial damage. For artificial damage, we provide free repairs with customer responsible for freight costs.

Q: What's your packing?

A: We use international export packaging and can print customer logos upon request.

Q: Can you do OEM/ODM?

A: Yes, we accept OEM/ODM orders and can sign confidentiality agreements.

Q: Can I have a sample?

A: Free samples available for adaptors, attenuators, patch cords, and pigtails with customer covering freight. Higher-value products require sample charge and freight prepayment, refundable upon order placement.

Q: How can I order?

A: Process: 1) Submit inquiry with product details and quantity; 2) Receive quotation with lead time; 3) Accept quotation and receive proforma invoice; 4) Production begins after payment; 5) Delivery confirmation and tracking provided; 6) Ongoing support for long-term cooperation.

Q: What are your payment terms?

A: T/T, Western Union, Paypal, MoneyGram. For large amounts: 50% deposit, 50% balance before delivery.
