12 24 Core OS2 OM3 OM4 MPO MTP Fiber Optic Cable with Plenum Rated Jacket

Brand Name:	New Light
Model Number:	MPO / MTP - MPO / MTP
MOQ:	1~10000
Price:	6~15
Packaging Details:	OPP bag + carton box
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

CE , ISO , RoHS

Name:

MPO MTP Cable

Material:

LSZH, OFNP Or OFNR

Mode Type:

OS2 OM3 OM4

Core Type:

12 24 Core

Connector:

MTP Mpo

Color:

Aqua,orange,yellow,Yellow/ Red/ Aqua

Supply Ability:

500 pcs per day

Highlight:

OS2 MPO MTP Cable

OM3 12 Core Fiber Optic Cable

OM4 24 Core Fiber Optic Cable

Product Description

12/24 Core OS2 OM3 OM4 MPO MTP Cable with Female Polarity B Plenum Rating

Product Overview

High-density MTP/MPO 24-fiber plenum-rated cables designed for efficient data center and high-performance network applications.

Key Features

Hi-density MTP/MPO 24-fiber connectors for reduced cabling space requirements
Push/Pull tab connectors for maximum accessibility in high-density installations
OM3 rated 50/125 Multimode fiber supporting up to 1000GbE speeds
24 times the density of SC style connectors
Eliminates need for long fan-out cables or individual duplex cable runs
Plenum rated jacket for safety compliance
Unique cable ID label for quality control and traceability
Each cable 100% tested for low insertion loss and back reflection
Test data supplied with each cable
Custom lengths available

Technical Specifications

Parameter	Specification
Connector	MPO/MTP (Female or Male)
Operation Temperature	-40°C to +80°C
Storage Temperature	-40°C to +85°C
Insertion Loss	Single-mode: ≤0.75dB (standard), ≤0.35dB (typical) Multi-mode: ≤0.50dB (standard), ≤0.35dB (typical)
Return Loss	Single-mode: ≥60dB Multi-mode: ≥35dB
MPO End Type	Male: with guide pin; Female: without guide pin
Fiber Count	8, 12 & 24 fiber options
Connector Types	MPO-female, MPO-male, FC, SC, ST, MU, LC, E2000
Fiber Modes	Single-mode (G652,G655,G657), multi-mode (50, 62.5, OM2, OM3, OM4)

Polarity Methods

The three polarity methods Type A, Type B and Type C are used to guarantee the right bi-directional allocation.

Packaging

Products are packaged in OPP bags and carton boxes to ensure protection during delivery and transportation.

Contact Us: WhatsApp +8613534063703

Frequently Asked Questions

Are you a manufacturer?

Yes, we are a manufacturer located in Shenzhen, China.

What's your MOQ?

MOQ can be 1 piece, but we recommend larger quantities for better pricing.

What's the price?

Pricing depends on quantity. Contact us with your requirements for competitive pricing.

Can you quote FOB price?

We typically ship via air courier (DHL, TNT, UPS, FEDEX). EXW or CFR pricing is preferred for most orders.

How is your quality?

We follow IEC and European standards with imported production equipment. All products are 100% tested before delivery.

What's your lead time?

We have three factories in China. For fiber optic patch cords, lead time is 2-3 working days for 5000 pieces. Regular products are in stock.

What's your warranty?

2-year warranty for patch cords for non-artificial damage. Artificial damage repairs are free, but freight is customer's responsibility.

What's your packing?

International export packaging. Custom logo printing available.

Can you do OEM/ODM?

Yes, we accept OEM/ODM orders and can sign confidentiality agreements.

Can I have a sample?

Free samples available for adaptors, attenuators, patch cords, and pigtails (freight paid by customer).

How can I order?

Contact us with product specifications and quantity. We'll provide pricing and lead time. Payment required before production.

What are your payment terms?

T/T, Western Union, Paypal, MoneyGram. For large orders: 50% deposit, 50% balance before delivery.
