Product Details:
|
| Fiber Mode: | SM / MM | Cable Length: | 50m, 100m, 200m, 250m, 300m, Etc. |
|---|---|---|---|
| Fiber Count: | 2 Core /4 Core | Insertion Loss: | ≤0.2dB |
| Storage Temperature: | -40℃~+85℃ | Return Loss: | ≥50dB |
| Fiber Type: | SM/MM | Fiber Grade: | G652D , G657A2 ,OM3, OM4 |
| Highlight: | TPU Jacket Optical Fiber Patch Cord,ODC Optical Fiber Patch Cord |
||
Parameter:
Fibra patch cord, also known as optic fiber patch cord, is a type of fiber optic cable that is used to connect one device to another for signal transmission. It is widely used in telecommunication, data center, local area network, and other networking applications.
The fibra patch cord is made of high-quality optical fiber and is designed to provide a reliable and efficient connection between devices. It is available in various lengths, with the most common options being 50m, 100m, 200m, 250m, and 300m. Custom lengths are also available upon request.
Storage Temperature:
-40℃~+85℃
Cable Length:
50m, 100m, 200m, 250m, 300m, etc.
Fiber Type:
SM (single mode) / MM (multimode)
Fiber Count:
2 Core / 4 Core
Durability:
≥1000 Times
The fibra patch cord is available in both single mode and multimode fibers, providing options for different network requirements. It can also come with 2 or 4 cores, allowing for multiple connections at the same time.
One of the key features of the fibra patch cord is its durability. It can withstand frequent plugging and unplugging, with a durability of at least 1000 times. This ensures a long-lasting and reliable connection for your network.
In conclusion, the optical fiber patch cord is an essential component for any network, providing a fast, secure, and stable connection between devices. With its various lengths, fiber types, and core counts, it can cater to different network needs. Plus, its durability ensures a long-term and efficient performance. Get your fibra patch cord today and experience seamless network connectivity!
| Technology | Full ceramic ferrule and sleeve | |
| Housing material | Nickel plated brass | |
| Mechanical performance | ODC plug | ≤1000 N tensile load≤30 N static side load |
| ODC socket | ≤30 N tensile load | |
| Installation torque force | min.1Nm | max.2Nm |
| Operating temperature | IEC 61300 – 2 – 22 | -40℃ up to +85℃ |
| Mating durability | 1000 cycle | |
| Ingress protection(mate) | IEC60529 | Ip 68 |
| Salt mist | IEC61300-2-26 | 30 days passed |
| Vibration | IEC61300-2-1 | Pass 10-500Hz/10g |
| Shock | IEC61300-2-9 | Pass 100g |
| Item | Description |
|---|---|
| Fiber Jumper | Optical Fiber Patch Cord |
| Fiber Type | SM/MM |
| Fiber Grade | G652D , G657A2 ,OM3, OM4 |
| Fiber Mode | Single Mode/Multimode |
| Cable Diameter | 5.0mm |
| Cable Length | 50m, 100m, 200m, 250m, 300m, Etc. |
| Return Loss | ≥50dB |
| Cable Jacket | TPU / PVC |
| Storage Temperature | -40℃~+85℃ |
| Application | FTTA, Telecom, CATV, LAN, Etc. |
| Color | Black |
Welcome to the world of high-speed data transmission with New Light's Optical Fiber Patch Cord! Our product is designed to meet the increasing demand for high-bandwidth and reliable network connections. With advanced technology and high-quality materials, our optic fiber patch cord is the perfect solution for your telecommunication needs.
New Light's Optical Fiber Patch Cord, model number NL01011, is a high-performance optic cable that is used to connect two devices for transmitting data. It is made in China and is ISO certified, ensuring its quality and reliability. The cable diameter is 5.0mm, making it easy to install and suitable for various applications.
| Brand Name | New Light |
|---|---|
| Model Number | NL01011 |
| Place of Origin | China |
| Certification | ISO |
| Minimum Order Quantity | 100 |
| Price | Negotiated |
| Packaging Details | 46*46*26cm |
| Delivery Time | 7-15 working days |
| Payment Terms | TT, Paypal |
| Supply Ability | 100000 |
| Durability | >=1000 Times |
| Cable Diameter | 5.0mm |
| Connector Type | LC, SC, ST, FC, MTRJ, MU, E2000, etc. |
| Operating Temperature | -40℃~+85℃ |
| Fiber Mode | SM / MM |
New Light's Optical Fiber Patch Cord is suitable for a wide range of applications, including:
Upgrade your network with New Light's Optical Fiber Patch Cord and experience high-speed and reliable data transmission. Contact us now for more information and to place your order!
Brand Name: New Light
Model Number: NL01011
Place of Origin: China
Certification: ISO
Minimum Order Quantity: 100
Price: Negotiated
Packaging Details: 46*46*26cm
Delivery Time: 7-15 working days
Payment Terms: TT, Paypal
Supply Ability: 100000
Operating Temperature: -40℃~+85℃
Cable Length Options: 50m, 100m, 200m, 250m, 300m, etc.
Color: Black
Cable Jacket Options: TPU / PVC
Return Loss: ≥50dB
Our optical fiber patch cords are designed to meet the growing demand for high density and high performance data centers. With our MPO jumper, you can easily achieve faster and more efficient data transmission.
At New Light, we understand that every project is unique and requires specific solutions. That's why we offer customization services for our fiber cables. From cable length to jacket material, we can tailor our products to fit your exact requirements.
With years of experience in the industry, New Light has become a trusted MPO jumper manufacturer. Our products are known for their low insertion loss and high performance, making them the perfect choice for your data center needs.
Choose New Light for all your optical fiber patch cord customization needs. Contact us today to learn more.
