Optical Fiber Patch Cord

Single Mode Fiber Optic Patch Cord with APC ≥60dB UPC ≥50dB and PC ≥45dB Return Loss for FTTH CATV Telecom

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

0086 13534063703

Contact Now

Single Mode Fiber Optic Patch Cord with APC ≥60dB UPC ≥50dB and PC ≥45dB Return Loss for FTTH CATV Telecom

Brand Name:	WNRLN
Model Number:	OS2-POL-SM-002
MOQ:	10 Pieces
Price:	USD 0.80-7.50 / Piece
Packaging Details:	Individual PE bag with dust caps, WNRLN branded box, export-grade corrugated carton
Payment Terms:	T/T,L/C,PayPal,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ISO 9001:2015, RoHS, CE, TIA/EIA-568-C.3

Fiber Type:

OS2 Single Mode (G652D / G657A1 / G657A2)

Connector Types:

SC, LC, FC, ST, E2000

Polish Type:

UPC / APC / PC

Insertion Loss (UPC):

≤0.20dB Typical, ≤0.30dB Max

Insertion Loss (APC):

≤0.20dB Typical, ≤0.30dB Max

Return Loss (UPC):

≥50dB

Return Loss (APC):

≥60dB

Return Loss (PC):

≥45dB

Cable Diameter:

0.9mm / 2.0mm / 3.0mm

Jacket Material:

PVC / LSZH / OFNP / OFNR

Ferrule Material:

Zirconia Ceramic

Operating Wavelength:

1310nm / 1550nm

Operating Temperature:

-40°C To +75°C

Supply Ability:

100000 Pieces per Month

Highlight:

UPC APC PC Polish Patch Cord

Single Mode OS2 SC LC Connector

High Return Loss FTTH CATV Jumper

Product Description

UPC/APC/PC Polish Single Mode Fiber Optic Patch Cord

Polish Types & Specifications

🟢

APC Polish (8° Angled)

≥60dB return loss with 8° angled end-face. Green connector body. The industry standard for CATV, RF over fiber, and FTTx PON networks where back reflection must be minimal.

🔵

UPC Polish (Ultra Physical Contact)

≥50dB return loss with domed end-face. Blue connector body. Ideal for telecom backbone, data center, and enterprise networks requiring stable low-loss connections.

⚫

PC Polish (Physical Contact)

≥45dB return loss with slightly domed end-face. Cost-effective solution for legacy installations and applications where ultra-high return loss is not critical.

Polish Type Comparison

Parameter	PC Polish	UPC Polish	APC Polish
End-Face Geometry	Slight Dome	Extended Dome	8° Angled
Return Loss	≥45dB	≥50dB	≥60dB
Insertion Loss (Typical)	≤0.30dB	≤0.20dB	≤0.20dB
Connector Body Color	Black / Beige	Blue	Green
Best Application	Legacy Systems	Telecom / Data Center	CATV / FTTx / RF

Technical Specifications

Fiber Type: OS2 Single Mode (G652D / G657A1 / G657A2)

Connector Types: SC, LC, FC, ST, E2000

Polish Options: UPC / APC / PC

Core Count: Simplex / Duplex

Cable Diameter: 0.9mm / 2.0mm / 3.0mm

Jacket Material: PVC / LSZH / OFNP / OFNR

Operating Wavelength: 1310nm / 1550nm

Operating Temperature: -40°C to +75°C

Ferrule Material: Premium Zirconia Ceramic

Test Standard: 100% OTDR Tested, IEC 61300-3-6 Compliant

Applications by Polish Type

APC — CATV & RF Over Fiber

FTTH PON, HFC networks, analog video transport, GPON/EPON OLT to ONU links

UPC — Telecom & Data Center

DWDM systems, SDH/SONET backbone, SAN fabric, enterprise structured cabling

PC — Legacy Installations

Existing multimode networks, test equipment connections, non-critical monitoring systems

Quality Assurance & Factory Direct Supply

Every patch cord undergoes 100% OTDR testing and end-face 3D interferometry inspection. Custom polish type, connector combination, and cable length available. Contact us for OEM/ODM inquiries and bulk wholesale pricing.

100% OTDR Tested 3D Interferometry ISO 9001 Factory Custom OEM/ODM
