NL-10GMC-06 10G SFP+ Media Converter with 10Gbps Data Rate, Up to 10km Transmission, and IEEE 802.3 Compliance

Brand Name:	NEW LIGHT OPTICS
Model Number:	NL-10GMC-06
MOQ:	10 Pieces
Price:	USD 15-85 / Piece
Packaging Details:	NEW LIGHT OPTICS branded color box with shock-proof foam, export-grade corrugated carton
Payment Terms:	T/T,L/C,PayPal,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

ISO 9001:2015, CE, RoHS, FCC

Product Type:

10G SFP+ Media Converter

Data Rate:

10Gbps (10GBase-T / 10GBase-X)

Fiber Port:

1 X SFP+ Slot (10GBase-LR/SR, LC Duplex)

Copper Port:

1 X 10GBase-T RJ45

Fiber Mode:

Single Mode (LR) Or Multimode (SR)

Wavelength:

1310nm (LR) / 850nm (SR)

Transmission Distance:

Up To 10km SMF / 300m MMF (OM3)

Power Supply:

DC 12V 1.5A External Adapter

Operating Temperature:

0°C To 50°C

Dimensions:

120mm X 90mm X 28mm

Weight:

0.35kg

Compliance:

IEEE 802.3an, IEEE 802.3ae, IEEE 802.3aq

Supply Ability:

50000 Pieces per Month

Highlight:

10G SFP Plus Converter

10GBase-T to Fiber LR SR

10 Gigabit Media Converter

Product Description

NL-10GMC-06 10G SFP Plus Media Converter 10GBase-T 10GBase-LR SR Conversion LC Duplex up to 10km

10G SFP+ Media Converter (NL-10GMC-06)

The NL-10GMC-06 10G SFP+ Media Converter by NEW LIGHT OPTICS TECHNOLOGY LIMITED bridges the gap between legacy 10GBase-T copper infrastructure and high-speed fiber optic networks. Supporting full 10Gbps line-rate conversion with an open SFP+ slot, this media converter accommodates 10GBase-LR (10km SMF), 10GBase-SR (300m MMF), and 10GBase-ER (40km) transceiver options. Purpose-built for enterprise 10G backbone upgrades, data center server-to-switch fiber links, and ISP 10G business access, the NL-10GMC-06 delivers wire-speed performance at a fraction of the cost of a 10G switch upgrade.

Key Features

Full 10Gbps wire-speed conversion between 10GBase-T copper and SFP+ fiber interface
Open SFP+ slot compatible with 10GBase-LR, SR, ER, ZR, and CWDM/DWDM transceivers
Auto-negotiation on 10GBase-T port supporting 10G/5G/2.5G/1G/100M fallback speeds
Jumbo frame support up to 16K bytes for iSCSI SAN and HPC cluster interconnects
IEEE 802.3x pause frame flow control for zero-loss transmission under burst traffic
Link Fault Pass-Through (LFP) for end-to-end link integrity monitoring
Compact desktop form factor with optional 19-inch rack-mount tray (fits 8 units)
LED status indicators for 10G link, SFP+ presence, activity, and alarm conditions

Technical Specifications

Parameter	Specification
Standards	IEEE 802.3an, 802.3ae, 802.3aq, 802.3x
Data Rate	10Gbps (10GBase-T / 10GBase-X)
Fiber Port	1 x SFP+ Slot (10GBase-LR/SR/ER, LC Duplex)
Copper Port	1 x RJ45 (10GBase-T, Auto-MDI/MDIX)
Copper Cable	Cat6a/Cat7 up to 100m
Fiber Type	SMF 9/125μm or MMF 50/125μm (OM3/OM4)
Max Distance	10km (LR), 300m (SR OM3), 400m (SR OM4)
Jumbo Frame	Up to 16K Bytes
Power Input	DC 12V 1.5A (External Adapter)
Power Consumption	< 8W
Operating Temp	0°C to 50°C
Humidity	10% to 90% (Non-Condensing)
MTBF	> 50,000 Hours
Dimensions	120 x 90 x 28 mm
Weight	0.35 kg

Applications

Enterprise 10G backbone fiber upgrade from copper, data center 10G server-to-ToR switch fiber links, ISP 10Gbps business dedicated line CPE, SAN/NAS storage replication over fiber, and 10G campus ring topology deployment.

NEW LIGHT OPTICS TECHNOLOGY LIMITED has specialized in fiber optic manufacturing for many years. Our comprehensive fiber optic product portfolio—spanning single-mode, multi-mode, bend-insensitive, and specialty fibers—serves customers in telecommunications, cloud infrastructure, industrial automation, medical imaging, and defense applications worldwide. With the explosive growth of MPO connectivity in 2026 and the accelerating demand for SFP-based fiber media converters, NEW LIGHT OPTICS is your trusted partner for cost-effective, high-quality fiber optic solutions.

Contact Information

📧 Email: sales03@newlightfiber.com

📞 Phone: +86 13534063703

👤 Contact Person: Alice

🏢 Company: NEW LIGHT OPTICS TECHNOLOGY LIMITED
