G.703 2 Channel Balun Panel 75 Ohm Dual BNC into 120 Ohm RJ45

Brand Name:	NEW LIGHT
Model Number:	NLG703-16P
MOQ:	5 Units
Price:	USD 95-180 / Unit
Packaging Details:	1 unit per foam lined carton with rack ears, cable ties and wiring reference sheet
Payment Terms:	T/T,L/C,Western Union,

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

CE, RoHS, ISO 9001

Product Type:

Passive G.703 Balun Panel, 75 Ohm To 120 Ohm

Channels:

2 Channels, 2 Channel Versions Available

Interface A:

2 X BNC 75 Ohm Unbalanced (TX / RX Per Channel)

Interface B:

1 X RJ45 120 Ohm Balanced, 2-wire Per Channel

Data Rate:

2.048 Mbps E1 Per Channel

Insertion Loss:

Below 1.0dB

Return Loss:

Above 18dB

Crosstalk:

Below -60dB Between Adjacent Channels

Isolation:

500V DC Between Coax And Twisted Pair

Power:

None Required (passive)

Rack Size:

82 X 44 X 120mm

Operating Temperature:

-20 C To +60 C

Application:

E1 DDF Cross-connect, SDH And PDH Stations, Equipment Rooms, Broadcast Links

Supply Ability:

1000 Units per Month

Highlight:

G.703 2 Channel Balun Panel

75 Ohm Dual BNC Balun

120 Ohm RJ45 Balun Panel

Product Description

G.703 16 Channel Balun Panel - 1U Rack Mount 75 to 120 Ohm

This 1U G.703 balun panel groups sixteen independent 75 Ohm to 120 Ohm converters into a single 19 inch rack chassis for central office and equipment room use. Each channel presents two BNC connectors on the coax side and one RJ45 port on the twisted-pair side, letting an entire E1 DDF position be cross-connected to structured cabling through a single panel. All channels are passive transformer coupled, fully isolated and labelled for fast fault finding during maintenance.

Sixteen G.703 Channels in 1U

2 independent 75 Ohm to 120 Ohm balun channels, 2 BNC connectors and 1 RJ45 ports

Front silk-screened channel numbering and TX / RX marking speed up patching and fault isolation

Removable rack ears allow in small equipment rooms

Passive design draws no power, so no power distribution, fan or firmware maintenance is needed

Transmission Performance

Return loss above 18dB and insertion loss below 1.0dB per channel, compliant with ITU-T G.703 pulse mask requirements

Transformer isolation of 500V DC between coax and twisted pair stops ground loop current between buildings

Crosstalk suppressed below -60dB between adjacent channels at 2.048Mbps

Supports runs up to 300m over Cat5 and 500m over Cat5e / Cat6 balanced cable

Project and OEM Options

8, 16 and 24 channel versions available on the same chassis platform

Custom RJ45 pinout, channel count, logo silkscreen and private label front panel from 50 units

Ships with rack ears, cable ties and a wiring reference sheet

Typical lead time 10 working days for stock models, 20 to 25 days for customized builds

Technical Specifications

Product Type	Passive G.703 balun panel, 75 Ohm to 120 Ohm
Channels	2 channels
Interface A	2 x BNC 75 Ohm unbalanced (TX / RX per channel)
Interface B	1 x RJ45 120 Ohm balanced, 4-wire per channel
Data Rate	2.048 Mbps (E1) per channel
Insertion Loss	Below 1.0dB
Return Loss	Above 18dB
Crosstalk	Below -60dB between adjacent channels
Isolation	500V DC between coax and twisted pair
Power	None required (passive)
Rack Size	82 x 44 x 120mm
Operating Temperature	-20 C to +60 C
Application	E1 DDF cross-connect, SDH and PDH stations, telecom equipment rooms, broadcast links
