RJ45 Ethernet Connector

G.703 2 Channel Balun Converter 75 Ohm BNC into 120 Ohm RJ45 for E1 Links

All Category

Switch And Socket

Mrs. Alice

sales03@newlightfiber.com

0086-13534063703

0086 13534063703

Contact Now

G.703 2 Channel Balun Converter 75 Ohm BNC into 120 Ohm RJ45 for E1 Links

Brand Name:	NEW LIGHT
Model Number:	NLG703-4D
MOQ:	10 Units
Price:	USD 28-52 / Unit
Packaging Details:	1 unit per foam lined carton with DIN clip kit and wiring sheet
Payment Terms:	T/T,L/C,Western Union,

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

CE, RoHS, ISO 9001

Product Type:

4 Channel Passive G.703 Balun Converter, 75 To 120 Ohm

Channels:

4 Independent Channels

Interface A:

8 X BNC 75 Ohm (TX / RX Per Channel)

Interface B:

4 X RJ45 120 Ohm Balanced

Mounting:

35mm DIN Rail Clip, Wall Bracket Optional

Data Rate:

2.048 Mbps E1 Per Channel

Insertion Loss:

Below 1.0dB Per Channel

Return Loss:

Above 18dB

Crosstalk:

Below -60dB

Isolation:

500V DC

Housing:

ABS With Steel DIN Clip

Operating Temperature:

-20 C To +70 C

Application:

Base Station Cabinets, Roadside Shelters, Railway Communications

Also Known As:

E1 Balun Converter, E1 Impedance Converter, Coax To Twisted Pair Converter, E1 Interface Converter

Search Terms:

E1 Balun Converter, E1 Impedance Converter, Coax To Twisted Pair Converter, E1 Interface Converter

Supply Ability:

3000 Units per Month

Highlight:

G.703 2 Channel Balun Converter

75 Ohm BNC to 120 Ohm RJ45 Balun

E1 Link Balun Converter

Product Description

G.703 2 Channel Balun Converter

Four independent 75 to 120 Ohm converters sit side by side in one DIN rail module, giving small sites the same patching flexibility as a rack panel without occupying rack space. Each channel takes a TX / RX BNC pair from the coax equipment and hands off a balanced four-wire signal on an RJ45 port, so E1 drops can leave the cabinet on ordinary Cat5 instead of twin coax. The module clips onto standard 35mm rail and is completely passive.

Four Channels in One DIN Module

2 independent transformer channels, 2 BNC connectors and 4 RJ45 ports inside a single housing
35mm DIN clip with locking tab holds the module in place during cable pulling and vibration
Channel numbers moulded on the front face reduce patching errors during commissioning

Designed for Tight Cabinets

Slim profile leaves room for adjacent breakers and terminal blocks in base station and roadside cabinets
No power feed, no earth reference needed, so no additional breaker or PDU capacity is consumed
Optional wall bracket for shelters where DIN rail space is already fully used

Performance and Options

Insertion loss below 1.0dB, return loss above 18dB and crosstalk below -60dB between channels
Transformer isolation of 500V DC stops ground loop hum between cabinets on different earths
Custom channel count, RJ45 pinout and private label front panel from 50 units

Technical Specifications

Product Type	2 channel passive G.703 balun converter, 75 to 120 Ohm
Channels	2 independent channels
Interface A	2 x BNC 75 Ohm (TX / RX per channel)
Interface B	1 x RJ45 120 Ohm balanced
Mounting	, wall bracket optional
Data Rate	2.048 Mbps E1 per channel
Insertion Loss	Below 1.0dB per channel
Return Loss	Above 18dB
Crosstalk	Below -60dB between channels
Isolation	500V DC between coax and twisted pair
Housing	ABS body
Operating Temperature	-20 C to +70 C
Application	Base station cabinets, roadside shelters, railway communications

Search Terms and Alternative Names

Buyers and engineers describe this item in several ways. The same unit is ordered as E1 Balun Converter, E1 Impedance Converter, Coax to Twisted Pair Converter or E1 Interface Converter. All of these names refer to the passive G.703 75 Ohm to 120 Ohm converter described above: coax on one side, balanced twisted pair on the other, no power supply and no configuration. If your tender documents or BOM use any of these terms, quote this model directly and we will ship the matching version.
