Item	SC/PC Series	SC/APC Series	LC/MU Series
Length	10.50±0.01mm	10.50±0.01mm	6.50±0.01mm
Outer-diameter	2.4990±0.0005mm	2.4990±0.0005mm	1.4990±0.0005mm
Inner-diameter	0.125~0.128mm	0.125~0.126mm	0.125~0.128mm
Concentricity	≤1um, ≤3um	≤0.5um, ≤1um	≤1um, ≤3um
Endface Type	Spherical Surface	Step or Conical	Spherical Surface

Tags:

fiber optic fast connector

fiber optic cable connectors

multimode fiber connectors

Products Details

Home > Products >

Fiber Optic Connectors

SC APC Fiber Optic Ceramic Ferrule with Flange for Anti Erosion Anti Aging and Precise Dimension

All Category

Optical Fiber Patch Cord

MPO MTP Patch Cord

MPO MTP Cable

MPO Cassette Module

Fiber Optic Patch Panel

Fiber Optic Pigtail

FTTH Termination Box

Fiber Optic Connectors

Quick Assembly Connector

Fiber Optic Adapter

Fiber Optic Attenuator

Fiber Optic Loopback

Fiber Optic Cables

Fiber Optic Tools

Fiber Optic Transceiver

Fiber Optic Splitter

Fiber Optic WDM

Fiber Optic Splice Closure

Copper Patch Cords

Rj45 Patch Panel

RJ45 Ethernet Connector

Drone Fiber Optic

Switch And Socket

SC APC Fiber Optic Ceramic Ferrule with Flange for Anti Erosion Anti Aging and Precise Dimension

Brand Name:	New Light
MOQ:	100
Price:	0.1~100
Packaging Details:	10 pcs per pack
Payment Terms:	T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Brand Name:

New Light

Certification:

Color:

White

Material:

Ceramic

Connector:

Polish:

APC

OEM:

Available

Name:

SC Fiber Optic Ceramic Ferrule

Minimum Order Quantity:

100

Price:

0.1~100

Packaging Details:

10 pcs per pack

Delivery Time:

7 working days

Payment Terms:

T/T,Western Union,MoneyGram

Supply Ability:

10000 pcs per month

Highlight:

fiber optic parts and accessories

fiber optic accessories

Product Description

SC APC Step Fiber Optic Ceramic Ferrule Anti Erosion / Anti Aging With Flange

SC/APC-Step Ferrule (with Flange)

Applications

CATV Systems
Telecom Networks
Optical Test Equipment
Local Area Networks
Wide Area Networks
Data Processing Networks

Key Features

Premium quality materials for superior performance
Excellent compatibility with industry standards
High reliability and operational stability
Precise dimensional accuracy
Low insertion loss and high return loss
High intensity with exceptional anti-erosion and anti-aging properties

Technical Specifications

Item	SC/PC Series	SC/APC Series	LC/MU Series
Length	10.50±0.01mm	10.50±0.01mm	6.50±0.01mm
Outer-diameter	2.4990±0.0005mm	2.4990±0.0005mm	1.4990±0.0005mm
Inner-diameter	0.125~0.128mm	0.125~0.126mm	0.125~0.128mm
Concentricity	≤1um, ≤3um	≤0.5um, ≤1um	≤1um, ≤3um
Endface Type	Spherical Surface	Step or Conical	Spherical Surface
