FC-FC Connector 2.0mm Diameter APC Polish Optical Fiber Patch Cord for High-Speed Data Transmission

Brand Name:	NewLight
MOQ:	1~100000
Price:	0.1~100
Packaging Details:	1 pcs per pack
Payment Terms:	T/T,Western Union,MoneyGram,Paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Name:

FC Fiber Optic Patch Cord

Diameter:

2.0mm

Model:

Single

Connector:

FC-FC

Color:

Yellow

Length:

1.5 Meter

Supply Ability:

1000000

Highlight:

duplex fiber patch cord

single mode fiber optic cable

Product Description

FC/APC-FC/APC Single Mode 9/125 Simplex Optical Fiber Patch Cord

This high-performance PVC yellow cable features FC/APC connectors and is designed for reliable optical fiber connectivity in various network applications.

Product Overview

Our optical fiber patch cords are manufactured using high-precision ceramic ferrules, premium optical cables, and precision connector components. The production process utilizes advanced grinding equipment and rigorous quality control to ensure optimal performance and durability.

Available Configurations

Connector Types

FC, SC, ST, LC, MT-RJ, MU, and more

Ferrule Endface Options

PC, UPC, APC polishing types

Fiber Types

Single mode, polarization-maintaining fiber
Multimode 50/125, multimode 62.5/125

Cable Diameters

0.9mm, 2.0mm, 3.0mm options available

Fiber Count

Single-core, dual-core, and multi-core connectors

Applications

Telecommunication networks
Video transmission systems
Gigabit Ethernet
Active device termination
Multimedia applications
Premise installations
FTTH and TTX applications
Local area networks
CATV systems

Technical Specifications

Parameter	Specification	Parameter	Specification
Connector	FC to FC	Jacket OD	2.0mm
Fiber Mode	9/125µm	Jacket Color	Yellow
Polish	APC to APC	Wavelength	1310/1550nm
Fiber Type	Simplex	Jacket Material	PVC
Insertion Loss	≤0.3dB	Interchangeability	≤0.2dB
Return Loss	≥50dB	Vibration	≤0.2dB
Operating Temperature	-40°C to 75°C	Storage Temperature	-45°C to 85°C
Polarity	A(Tx) to B(Rx)	Fiber Grade	G652D

Key Features

Excellent versatility and interchangeability
Stable, reliable connections with high repeatability
Low insertion loss and high return loss performance
