|Product Name:||1 In 2 Out Mini Type PLC Splitter||Connector Type:||SC / E2000|
|Mode Type:||Single Mode||OEM / ODM:||Acceptable|
|Tube Materials:||Stainless Steel||Certificate:||CE , ISO , RoHS|
|Cable Length:||1~3m||Cable Diameter:||0.9mm , 0.6mm, 0.25mm|
fiber optic plc splitter,
single mode fiber splitter
PLC Splitters is used to distribute optical signals to multiple locations for processing. In optical networks, it is often necessary to split an optical signal into many identical signals, or to combine many signals into a single signal. PLC Splitter is a type of optical power management device that is fabricated using silica optical waveguide technology. They are designed for FTTx in PON, CWDM, DWDM and optical cable TV System. It’s also responsible to distribute optical signals from Central Office (CO) to multiple premise locations.We provides whole series of 1*N and 2*N splitter products that are tailored for specific applications.
•Our PLC splitters are tested based on the strictest standards of the industry, and we guaranteequality, turnaround and competitive pricing.
Rollball provides whole series of 1xN and 2xN splitter products that are tailored for specific applications. All products meet GR-1209-CORE and GR-1221-CORE requirements.
Optical Signal Distribution
Low Insertion loss
Good channel-to-channel uniformity
Wide Operating Wavelength:From 1260nm to 1650nm
Wide Operating Temperature: From -40°C to 85°C
High Reliability and Stability
|Operating Wavelength (nm)||1260~1650|
|Fiber Type||SMF-28e or customer specified|
|Insertion Loss (dB)(S/P Grade)||4.0/3.8||7.3/7.0||10.5/10.2||13.7/13.5||16.9/16.5||21.0/20.5|
|Loss Uniformity (dB)||0.4||0.6||0.8||1.2||1.5||2.5|
|Return Loss (dB) (S/P Grade)||50/55||50/55||50/55||50/55||50/55||50/55|
|Polarization Dependent Loss(dB)||0.2||0.2||0.3||0.3||0.3||0.4|
|Wavelength Dependent Loss(dB)||0.3||0.3||0.3||0.5||0.5||0.5|
|Temperature Stability(-40~85 °C)(dB)||0.5||0.5||0.5||0.5||0.5||0.5|
|Operating Temperature (°C)||-40~85|
|Storage Temperature (°C)||-40~85|
|Module Dimension (mm) (L×W×H)||100×80×10||100×80×10||100×80×10||120×80×18||140×115×18||140×115×18|
The tube size(mm): 50x4x4
The PLC optical splitter MINI module not only available in a variety of split modes and package types, but also can be customized according to customer requirements.
