Fiber Optic Filter DWDM Device with 3 Ports 100G 200G and Low Insertion Loss for WDM Systems

Brand Name:	New Light
Model Number:	WDM
MOQ:	1
Price:	1~30
Packaging Details:	export packing
Payment Terms:	T/T,Western Union,MoneyGram,paypal

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Mode Type:

Single Mode

Insertion Loss:

≤ 2.5 DB

Connector Type:

SC/UPC

Nuber Of Channels:

8 Channel

Wavelength:

1470-1610nm

Passband Ripple:

≤0.30dB

Return Loss:

≥45dB

Derectivity:

≥50dB

Fiber Type:

Corning SMF-28 Ultra

Supply Ability:

1000000

Highlight:

wdm in optical fiber

wall mount fiber termination box

Product Description

Fiber Optic Filter 3 Ports 100G 200G 1X2 DWDM Device

DWDM ITU Components represent years of telecommunications expertise in thin-film filter technology. These 3-port devices are available on ITU channel spacing of 200 GHz and exceed Telcordia GR-1221 requirements, delivering reliable performance in various system applications.

Key Features

Low insertion loss
High channel isolation
Low polarization dependent loss
Exceptional reliability and stability

Applications

Access networks
Metro WDM systems
Long haul WDM systems
Enterprise networks

Technical Specifications

Item	Unit	Parameters
Channel spacing	GHz	200
Wavelength range		C- or L-band ITU channels 186.6 to 196.1 THz
Passband	GHz	≥+/- 33
Transmission passband ripple	dB	≤0.3
Transmission insertion loss	dB	≤1.0
Reflection passband ripple	dB	≤0.2
Reflection insertion loss	dB	≤0.4
Transmission isolation (adj channel)	dB	≥30
Transmission isolation (non-adj channel)	dB	≥50
Reflection isolation	dB	≥13
Polarization dependent loss	dB	≤0.2
Polarization mode dispersion	ps	≤0.2
Directivity	dB	≥50
Return loss	dB	≥45
Optical power handling	mW	≥500
Tensile Load	N	≥5
Operating temperature range		-5 to 70
Storage temperature range		-40 to +85 °C
Fiber type		SMF-28e
Package dimension	mm	5.5 x 34mm

Note: All specifications are based on devices without connectors and guaranteed over wavelength, polarization and temperature.

Dimensions Drawing

Spectral Plot

Ordering Information

Product	Channel Frequency	Tube	Fiber length	Connector
200G DWDM Filter	ITU Grid In C-band	1=250um fiber	1=0.5+/-0.1m	0=No connector
		2=900um fiber	2=1.0+/-0.1m	1=FC/UPC
		3=Others	3=others	2=FC/APC
				3=SC/UPC
				4=SC/APC
				5=LC

Frequently Asked Questions

Are you the real factory?

Yes, we are the real factory with 16 years of manufacturing history.

What is your fiber brand?

Fiber brands including YOFC FiberHome.

What are your main products?

Fiber optic patch panels, fiber MPO & MTP cassettes, MPO & MTP cables, outdoor fiber optic cables, indoor fiber optic cables, FTTH drop cables, ADSS cables, indoor armored patch cords, and optical patch cords (SC, LC, FC, ST, MTP, MPO).

What is your product quality guarantee period?

20 years guarantee for fiber optic cable.

Do you have certificate for raw material?

We build long-term relationship cooperation with qualified ISO9001 ROHS raw material suppliers.

What is your delivery time?

Within 48 hours for normal kinds of fiber optic products.

What is your minimum order quantity (MOQ)?

MOQ for Fiber Optic Cable Patch Panel: 10 sets. There is no MOQ required for fiber optic patch cords, as we maintain stock for normal kinds.

Do you have distributors in other countries or domestic?

Until now we sell our products to customers directly and offer factory pricing.

What payment methods do you accept?

For large orders: T/T. For small orders: T/T and Paypal are acceptable.

What are your shipping and delivery options?

For large orders: by sea (LCL or FCL). For small orders: by sea (LCL), by air, or by courier services - any of which is optional.
