Dual-Shielded Weatherproof RJ45 Connector for CAT7 Ethernet with Industrial-Grade Performance

Brand Name:	NEW LIGHT
Model Number:	NLC001
MOQ:	100
Price:	0.02~10
Packaging Details:	export packing
Payment Terms:	L/C,T/T,Western Union,MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO ,ROSH

Name:

Rj45 Connector

Application:

Cat6 , Cat6a , Cat7

Material:

Tester:

Fluke-tested

Network Module:

Cat5 / Cat6

Surface:

Cat5e:

100Mhz

Cat6:

250 MHz

Cat7:

600MHz

Cable:

UTP / SFTP / SSTP

Supply Ability:

1000000

Highlight:

Industrial RJ45 Connectors

Weatherproof RJ45 Connectors

Weatherproof Industrial RJ45 Connectors

Product Description

Industrial-Grade Dual-Shielded RJ45 Connectors (CAT6/CAT7 Compatible)

Dual-shielded connectors with waterproof gel for outdoor or industrial use. Compatible with CAT6/7 cables, ensuring versatility and rugged performance.

Key Features

Dual-Shielded Design

Enhanced EMI/RFI shielding with foil and braided layers for superior signal integrity in electrically noisy environments
Reduces crosstalk and interference, ensuring stable data transmission up to 10 Gbps (CAT6A/CAT7 standards)

Weatherproof & Durable

IP67-rated waterproof and dustproof construction
Sealed with waterproof gel-filled housing to protect against moisture, humidity, and harsh weather conditions
UV-resistant outer jacket for prolonged outdoor use

Industrial-Grade Performance

Compatible with CAT6, CAT6A, and CAT7 Ethernet cables
Rugged zinc alloy shell with corrosion-resistant coating for mechanical durability
Operating temperature range: -40°C to +85°C (-40°F to +185°F)

Secure Connectivity

Gold-plated contacts (50μ") ensure low resistance and high conductivity
Tool-free or crimp-style installation options available
360° shielding termination for consistent grounding

Technical Specifications

Standards Compliance	IEEE 802.3, TIA/EIA-568-C.2, ISO/IEC 11801
Shielding	Dual-layer (foil + braided shield)
Contact Rating	1.5A, 125V AC
Insertion Loss	≤0.3 dB @ 250 MHz
Return Loss	≥20 dB @ 250 MHz
Data Rate	Up to 10 Gbps (600 MHz bandwidth for CAT7)
Ingress Protection	IP67
Cable Compatibility	22-28 AWG stranded or solid conductors
Durability	≥1,000 mating cycles

Applications

Industrial automation systems (PLC, sensors, robotics)
Outdoor surveillance cameras and network infrastructure
Marine, mining, and oil/gas environments
Transportation networks (railways, traffic control)
Smart grid and renewable energy systems

Certifications & Compliance

RoHS, REACH compliant
UL/cUL listed (where applicable)
IEC 60529 IP67 rating
Flame-retardant: UL94 V-0 (housing material)
